18
Temperature Control
For convenience, the temperature control is preset at the factory.
When you first install your refrigerator, make sure the control is
still preset as shown above.
WRT519
WRT108
WRT138
WRT148
WRT318
WRT348
WRT549
ART308
ART318
MRT118
WRT541
WRT511
WRT134
WRT314
WRT104
WRT106
IMPORTANT:
� The recommended setting should be correct for normal
household refrigerator use. The controls are set correctly when
milk or juice is as cold as you like and when ice cream is firm.
� Wait 24 hours for your refrigerator to cool completely before
adding food. If you add food before the refrigerator has cooled
completely, your food may spoil.
NOTE: Adjusting the refrigerator and freezer controls to a
colder than recommended setting will not cool the
compartments any faster.
� If the temperature is too warm or too cold in the refrigerator or
freezer, first check the air vents to be sure they are not blocked
before adjusting the controls.
Adjusting the Temperature Control
NOTE: Except when starting the refrigerator, do not adjust the
control more than one setting at a time. Wait 24 hours between
adjustments for the temperature to stabilize
� If you need to adjust the temperature in either the refrigerator
or freezer compartment, use the settings listed in the chart
below as a guide.
NOTE: Adjusting the refrigerator and freezer controls to a
colder than recommended setting will not cool the
compartments any faster.
� If the temperature is too warm or too cold in the refrigerator or
freezer, first check the air vents to be sure they are not blocked
before adjusting the controls.
In some models
� Press the Temp Setting button to toggle among the four LED
lights which indicate the temperature setting. Reading from left
to right, the LED in the first position is the least cold. The LEDs
indicate increasingly colder settings as you continue to the
right until all four LEDs are illuminated.
NOTE: For the first to fourth setting, only one LED of the four
LEDs will be lit. All four LEDs will be lit when you have reached
the coldest setting.
CONDITION/REASON CONDITION/REASON
Refrigerator too warm Temp control one setting
higher
Refrigerator too cold Temp control one setting
lower
Freezer too warm/too little ice* Airflow or Temp control one
setting higher
Freezer too cold Airflow or Temp control one
setting lower
*Ice makers and Ice maker kits are available on select models.
Cooling ON/OFF
� To turn cooling off, press and hold the Setting button for
4 seconds until all lights stay on for 1 second. To turn cooling
back on, press and hold the Setting button again for
4 seconds.
NOTE: Neither compartment will cool when the control is set to
Off.
Airflow Control
The Airflow control regulates the amount
of air flowing between the freezer and the
refrigerator compartments. Changing the
Airflow setting to Min removes cool air
from the freezer and uses it to cool the
refrigerator.
When you plug in the refrigerator for the
first time, turn the Airflow control to the
Recommended setting.
Adjusting The Airflow Control
If you want to temporarily increase the cold airflow to a specific
compartment, adjust the control:
� Max - Increase airflow to the freezer
� Min - Increase airflow to the refrigerator
IMPORTANT: Once the performance is achieved, return the
Airflow control to the recommended setting to keep the
refrigerator operating at optimum efficiency.
CONDITION/REASON ADJUSTMENT
Heavy ice use* Max
Hot room temperature Max – to maintain ice making
production rate
Large quantity of groceries Min – to quickly chill food and
beverages
*Ice makers and ice maker kits are available on select models.
