13
Ice Maker and Storage Bin
� Allow 24 hours to produce the first batch of ice. Discard the
first three batches of ice produced.
� The quality of your ice will be only as good as the quality of the
water supplied to your ice maker. Avoid connecting the ice
maker to a softened water supply. Water softener chemicals
(such as salt) can damage parts of the ice maker and lead to
poor quality ice. If a softened water supply cannot be avoided,
make sure the water softener is operating properly and is well
maintained.
� Do not use anything sharp to break up the ice in the storage
bin. This can cause damage to the ice container and the
dispenser mechanism.
� Do not store anything on top of or in the ice maker or storage
bin.
Style 1
Turning the Ice Maker On/Off:
The On/Off switch, located on the left wall of the freezer door, can
only be accessed when the ice storage bin has been removed.
See the following section for bin removal instructions.
� To turn on the ice maker, flip the switch to the On (up) position.
� To manually turn off the ice maker, flip the switch to the Off
(down) position.
NOTE: The ice maker has an automatic shut-off to keep the
storage bin from overfilling during normal operation. As ice is
made, the ice cubes will fill the ice storage bin, and the ice cubes
will raise the shut-off arm to the Off (arm up) position. When the
storage bin is at full capacity, the ice maker will automatically stop
ice production, but the ice maker On/Off switch will remain in the
On (up) position.
Ice production Off (Shut-off
arm up)
Ice production On (Shut-off
arm down)
Removing and Replacing the Ice Storage Bin:
1. Press down the release lever and tilt the bucket outward. Use
both hands to hold the base of the storage bin, and then lift it
up and out.
A. Release lever
NOTE: It is not necessary to flip the ice maker On/Off switch
to the Off (down) position when removing the storage bin. The
storage bin sensor, located on the left wall (right wall on some
models) of the freezer door, stops the ice maker from
producing ice if the door is open or the storage bin is removed.
A. On/Off switch
B. Storage bin sensor
2. Replace the bin by sliding it onto the door, and then tilting it
back into an upright position. The release lever will click when
the bin is securely in place.
Style 2
Turning the Ice Maker On/Off:
� To turn on the ice maker, lower the wire shut-off arm to the On
position.
� To manually turn off the ice maker, lift the wire shut-off arm to
the Off (arm up) position and listen for the click. Ice can still be
dispensed, but no more can be made.
NOTE: The ice maker has an automatic shut-off to keep the
storage bin from overfilling during normal operation. As ice is
made, the ice cubes will fill the ice storage bin, and the ice cubes
will raise the wire shut-off arm to the Off (arm up) position. Do not
force the wire shut-off arm up or down.
Removing and Replacing the Ice Storage Bin:
1. Pull the covering panel up from the bottom.
2. Lift the wire shut-off arm so it clicks into the Off (up) position.
