14
3. Lift up the front of the storage bin and pull it out.
4. Replace the bin by pushing it in all the way or the dispenser
will not work.
5. To restart ice production, lower the wire shut-off arm to the On
(down) position. Make sure the door is closed tightly.
Style 3
Turning the Ice Maker On/Off:
� To turn on the ice maker, lift open the ice maker door and lower
the wire shut-off arm to the On position.
� To manually turn off the ice maker, lift the wire shut-off arm to
the Off (arm up) position and listen for the click. Ice can still be
dispensed, but no more can be made.
NOTE: The ice maker has an automatic shut-off to keep the
storage bin from overfilling during normal operation. As ice is
made, the ice cubes will fill the ice storage bin, and the ice cubes
will raise the wire shut-off arm to the Off (arm up) position. Do not
force the wire shut-off arm up or down.
Removing and Replacing the Ice Storage Bin:
1. Lift and hold open the ice maker door.
2. Lift the wire shut-off arm so it clicks into the Off (up) position.
Release the ice maker door.
3. Lift up the front of the storage bin and pull it out.
4. Replace the bin by pushing it in all the way or the dispenser
will not work.
5. To restart ice production, lift open the ice maker door and push
the wire shut-off arm down to the On position.
Style 4
Turning the Ice Maker On/Off:
The On/Off switch is located on the bottom of the ice maker, which
can be accessed by lifting and opening the ice maker door.
� To turn on the ice maker, lift open the ice maker door, and flip
the switch to the On (right) position.
� To manually turn off the ice maker, lift open the ice maker door,
and flip the switch to the Off (left) position. Ice can still be
dispensed, but no more can be made.
NOTE: Your ice maker has an automatic shut-off to keep the
storage bin from overfilling during normal operation. As ice is
made, the ice cubes will fill the ice storage bin, and the ice cubes
will raise the shut-off arm to the Off (arm up) position. When the
storage bin is at full capacity, the ice maker will automatically stop
ice production, but the ice maker On/Off switch will remain in the
On (up) position.
Removing and Replacing the Ice Storage Bin:
1. Pull the covering panel up from the bottom.
2. Lift the plastic shut-off arm so it clicks into the Off (up)
position.
3. Lift up the front of the storage bin and pull it out.
4. Replace the bin by pushing it in all the way or the dispenser
will not work.
5. To restart ice production, lower the plastic shut-off arm to the
On (down) position. Make sure the door is closed tightly.
Style 5
Turning the Ice Maker On/Off:
The ON/OFF switch is located on the right side of the ice maker,
which can be accessed by lifting and opening the ice maker door.
� To turn on the ice maker, lift open the ice maker door, and flip
the switch ON/OFF to the ON (I) position.
� To manually turn the ice maker off, lift open the ice maker door,
and flip the switch ON/OFF to the OFF (O) position.
NOTE: The ice maker has an automatic shut-off to keep the
storage bin from overfilling during normal operation. As ice is
made, the ice cubes will fill the ice storage bin and the ice cubes
will raise the wire shut-off arm up. When the storage bin is at full
capacity, the ice maker will automatically stop ice production, but
the ice maker ON/OFF rocker switch will remain in the ON (I)
position. Do not force the wire shut-off arm up or down.
