9
� To remove the handle, grasp the lower part of the handle
firmly, slide the handle up and pull the handle straight out from
the door.
� To replace the handle, position the handle so that the large
holes in the mounting clips are down and align the holes with
the door studs. Rotate the handle so that the mounting clips
are flat against the door and slide the handle down to engage.
FREEZER DOOR HANDLES
Freezer Door Handle Style 1
A. 3/32” Setscrew
� Using a 3⁄32" or 1⁄8" hex key, loosen the two setscrews located
on the side of each handle. Pull the handle straight out from
the drawer. Make sure you keep the screws for reattaching the
handles.
� To replace the handles, reverse the directions.
Freezer Door Handle Style 2
A. Handle Trim C. Freezer Drawer Handle
B. Flat–Head Handle Screws
� Remove the screw cover.
� Remove the handle assembly. Keep all parts together.
� To replace the handles, reverse the directions.
Freezer Door Handle Style 3
A. Flat–Head Handle Screws
� Remove screws and handle.
� To replace handle, reverse directions.
Freezer Door Handle Style 4
A. Flat–Head Screws B. Freezer Drawer Handle
� Remove screws and handle.
� To replace the handles, reverse the directions.
Freezer Door Handle Style 5
� To remove the handle, grasp the lower part of the handle
firmly, slide the handle up and pull the handle straight out from
the door.
� To replace the handle, position the handle so that the large
holes in the mounting clips are down and align the holes with
the door studs. Rotate the handle so that the mounting clips
are flat against the door and slide the handle down to engage.
Remove Doors and Hinges
STANDARD DOOR
Hex Head Top Hinge Screw
Standard Door - Freezer drawer models
1. Unplug refrigerator or disconnect power
2. Keep the refrigerator door closed until you are ready to lift it
free from the cabinet.
NOTE: Provide additional support for the door while the
hinges are being moved. Do not depend on the door gasket
magnets to hold the door in place while you are working.
