DAILY USE
SWITCHING THE HOB ON/OFF
To turn the hob on, press the power button for around 1 second. To turn the
hob o, press the same button again, and all cooking zones will be deactivated.
POSITIONING
Do not cover the control panel symbols with the cooking pot.
Please note: In the cooking zones close to the control panel, it is advisable to
keep pots and pans inside the markings (taking both the bottom of the pan
and the upper edge into consideration, as this tends to be larger).
This prevents excessive overheating of the keypad. When grilling or frying,
please use the rear cooking zones wherever possible.
ACTIVATING/DEACTIVATING COOKING ZONES AND ADJUSTING POWER
LEVELS
OFF
P
18
To activate the cooking zones:
Move your nger horizontally across the scroll keypad (SLIDER) of the required
cooking zone to activate it and adjust the power. The level will be shown in
line with the area and the indicator light identifying the active cooking zone.
The ”P” button can be used to select the fast heating function (Booster).
To deactivate the cooking zones:
Select the “OFF“ button at the beginning of the scroll keypad.
3 sec
OK
CONTROL PANEL LOCK
To lock the settings and prevent it from accidentally switching on, press and
hold the OK/Key lock button for 3seconds. A beep and a warning light above
the symbol indicate that this function has been activated. The control panel
is locked except for the switching o function (
). To unlock the controls,
repeat the activation procedure.
TIMER
There are two timers - one controls the left-hand cooking zones, while
the other controls the right-hand cooking zones.
To activate the timer:
Press the “+“ or “−“ button to set the desired time on the cooking zone in use.
An indicator light will be activated in line with the specic symbol
. Once
the set time has elapsed, a beep will sound, and the cooking zone will switch
o automatically.
The time can be changed at any point, and several timers can be activated
simultaneously.
In case 2 timers on the same side of the hob are activated simultaneously,
“Zone selection indicator“ ashes and the relative cooking time selected is
displayed on the central display.
To deactivate the timer:
Press the “+“ and “−“ buttons together until the timer is deactivated.
TIMER INDICATOR
This LED (when ON) indicates that the timer has been set for the cooking zone.
FUNCTIONS
FLEXICOOK
By selecting the “FLEXICOOK“ button, you can combine two cooking zones
and use them at the same power by covering the entire surface with a
large pot or partially with a round/oval pot.
The function always remains on and, when using only one pot, can be
moved over the entire area. In this case, both left-hand scroll keypads can be
used indierently.
Ideal for cooking with oval or rectangular pots or with pan supports.
To deactivate the function, press the “FLEXICOOK“ button.
N.B. Special functions cannot be selected when using this feature.
IMPORTANT: Place the pots in the center of the cooking zone so that they
cover at least one of the reference points (as shown below).
6
TH
SENSE
The “6
th
Sense“ button activates the special functions.
Place the pot in position and select the cooking zone.
Press the “6
th
Sense“ button. The display of the selected area will show “A“.
The indicator for the rst special feature available for the cooking zone will
light up.
Select the desired special function by pressing the “6
th
Sense“ button one or
more times.
The function is activated once the
3 sec
OK
button has been pressed to conrm.
To select another special function, press “OFF“ and then the “6
th
Sense“ button
to choose the required function.
To deactivate the special functions and return to manual mode, press “OFF“.
The power level when using special functions is pre-set by the hob and cannot
be modied.
MELTING
This function allows you to bring food to the ideal temperature for
melting and maintain the food condition without the risk of burning.
This method is ideal, as it does not damage delicate foods such as
chocolate and prevents them from sticking to the pot.
KEEP WARM
This feature allows you to keep your food at an ideal temperature, usually after
cooking is complete or reducing liquids very slowly.
Ideal for serving foods at the perfect temperature.
SIMMERING
This function is ideal for maintaining a simmering temperature, allowing you
to cook food for long periods with no risk of burning.
Ideal for long-cooking recipes (rice, sauces, roasts) with liquid sauces.
P
OFF
18
P
OFF
18
P
OFF
18
P
OFF
18
3 sec
