5
EN
LOADING THE RACKS
LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc. Large plates and lids should
ideally be placed at the sides to avoid interferences with the spray arm.
The lower rack has tip-up supports which can be used in a vertical po-
sition when arranging plates or in a horizontal position (lower) to load
pans and salad bowls easily.
(loading example for the lower rack)
CUTLERY BASKET
It is tted with top grids for improved
cutlery arrangement.
It must only be positioned at the front
of the lower rack.
Knives and other utensils with sharp
edges must be placed in the cutlery
basket with the points facing down-
wards or they must be positioned
horizontally in the tip-up compart-
ments on the upper rack.
POWER CLEAN®
Power Clean® uses the special water
jets in the rear of cavity to wash more
intensively the high dirty items. The
lower rack has a Space Zone, a special
pull-out support in the rear of the rack
that can be used to support frying
pans or baking pans in upright position, thus taking up less space.
Placing the pots/casseroles faced to the Power Clean® component please
activate the POWER CLEAN® on the panel.
How to use Power Clean®:
1. Adjust the Power Clean® area G
folding down the rear plate hol-
ders to load pots.
2. Load pots and casseroles inclined
vertically in Power Clean® area.
Pots have to be inclined towards
the power water jets.
UPPER RACK
Load delicate and light dishes:
glasses, cups, saucers, low salad
bowls.
(loading example for the upper rack)
ADJUSTING THE HEIGHT OF THE UPPER RACK
The height of the upper rack can be adjusted:
high position to place bulky crockery in the
lower basket and low position to make the
most of the tip-up supports by creating more
space upwards and avoid collision with the
items loaded into lower rack.
The upper rack is equipped with a Upper Rack
height adjuster (see gure), without pressing
the levers, lift it up by simply holding the rack
sides, as soon as the rack is stable in its upper
position. To restore to the lower position, press
the levers A at the sides of the rack and move
the basket downwards.
We strongly recommend that you do not adjust the height of the rack
when it is loaded.
NEVER raise or lower the basket on one side only.
FOLDABLE FLAPS WITH ADJUSTABLE POSITION
The side foldable aps can be fold or
unfold to optimize the arrangement of
crockery inside the rack.
Wine glasses can be placed safely
in the foldable aps by inserting
the stem of each glass into the
corresponding slots.
Depending on the model:
– to unfold the aps there is needed
to slide it up and rotate or release it
from the snaps and pull it down.
– to fold the aps there is needed to
rotate it and slide aps down or pull
it up and attach aps to the snaps.v
