9
3. Extend side curtains
Extend side curtains out until they t into the window channels.
5. Install screws into window sash
Use a 1/8" drill bit to drill a starter hole through the holes in the
top rail and the top corners of the side curtains into the window
sash.
Secure with three 1/2" screws through the holes in the top rail
and side curtain and into the window sash.
A
B
7. Install foam seal
A. Top of lower
window sash
B. Foam seal
Insert the foam seal without adhesive strip between the top of the
lower window sash and the glass of the upper window.
Remove any remaining clear plastic lm from the control panel
and plastic front panel.
4. Install side curtain brackets
Slide a side bracket over the bottom corner of each side curtain
frame.
Using a 1/8" drill bit, drill a starter hole through the hole in the
side curtain bracket and into the windowsill.
Secure each bracket to the windowsill with a 3/4" screw.
6. Secure lower sash
Attach the right angle sash lock with a 3/4" screw.
