ASSEMBLY & INSTALLATION WINDOW MOUNTING
Step 1: Window Requirements
Step 2: Testing
Before installing your AC, test it to make sure it works properly,
and your outlet has the proper power level.
outlet (never use a powerstrip or other device). and turn it on.
Next, use the Mode button on your control panel to change
the AC to Cool Mode and press the down arrow to set the
temperature to the lowest setting. After 3 minutes, the AC
should be blowing cool air. lf so, please continue to the next step.
lf not, see detailed troubleshooting tips at support.
1. This air conditioner is designed to be installed in a standard
single-hung or double-hung window with a window width between
25" and 36" (645mm - 915mm).
2. The lower sash (the lower part of the window that moves up and
down) must allow for 14.5" of vertical clearance when open.
metal.
4. The electrical outlet must be within reach of the power cord.
(Electrical outlets only, no power strips or other outlets allowed.)
NOTE: Store the air conditioner in its product box while not in use.
25-36 inch
645-915 mm
14.5 inch
368mm
Exterior
Wall
Stool
Sill
Interior
Wall
7
Step 3: Prepare Air Conditioner for Installation
Unpack the Air Conditioner
Remove Packaging Materials:
Gently handle the air conditioner while unpacking the unit.
Remove tape and glue residue from surfaces before
turning on the air conditioner. Rub a small amount of liquid
or abrasive cleaners to remove tape or glue. These products can
damage the surface of the air conditioner.
Remove any packaging materials inserted into the side louvers.
Dispose of/recycle packaging materials in an appropriate way.
damp cloth and dry.
3
WARNING
Excessive Weight Hazard
Use two or more people to move and install
air conditioner.
Failure to do so can result in back or other injury.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
air conditioner.
Failure to do so can result in back or other injury.
