EN
Quick Guide
3
CLEANING THE FILTER ASSEMBLY
A
A
B
C
1 2 3 4
The dishwasher must not be used without l-
ters or if the lter is loose.
It is important when reinstalling the lter that
the two triangles shown on the zoom meet (Fig 1).
In case you nd foreign objects (such as broken
glass, porcelain, bones, fruit seeds etc.) please re-
move them carefully.
Inspect the trap and remove any food residues.
NEVER REMOVE the wash-cycle pump protec-
tion (shown by an arrow) (Fig 4).
CARE AND MAINTENANCE
More information in the Daily Reference Guide on website.
CLEANING THE SPRAY ARMS
On occasions, food residue
may become encrusted onto
the spray arms and block the
holes used to spray the water. It
is therefore recommended that
you check the arms from time
to time and clean them with
asmall non-metallic brush.
To remove the upper spray you
must remove it together with
the manifold.
The lower spray arm may be removed by
pulling it upwards and rotating it an-
ti-clockwise. Mounting back the spray
arm is by pulling it down and rotating it
clockwise.
The top spray arm may be removed by
pressing it up and then rotating it an-
ti-clockwise. Mounting back the spray
arm is by pulling it upwards and rotating
it clockwise.
CUTLERY RACK
The third rack was
designed to house
the cutlery. Arrange
the cutlery as shown
in the gure.
A separate arrange-
ment of the cutlery
makes collection
easier after washing and improves washing and drying performance.
Knives and other utensils with sharp edges must be positioned with
the blades facing downwards.
The cutlery rack is equipped with two sliding side trays to make the most
of the height of the space below and enable the loading of high items into
the upper rack.
UPPER RACK
Load delicate and light dishes: glasses, cups,
saucers, low salad bowls.
The upper rack has tip-up supports which can
be used in a vertical position when arranging
tea/ dessert saucers or in a lower position to
load bowls and food containers.
(loading example for the upper rack)
ADJUSTING THE HEIGHT OF THE UPPER RACK
The height of the upper rack can be adjusted: ahigh po-
sition to place bulky crockery in the lower basket and
alow position to make the most of the tip-up supports
by creating more space upwards and avoiding collision
with the items loaded into the lower rack.
We strongly recommend that you do not adjust the
height of the rack when it is loaded. NEVER raise or
lower the basket on one side only.
FOLDABLE FLAPS WITH ADJUSTABLE POSITION
The side foldable aps can be folded or unfolded to opti-
mize the arrangement of crockery inside the rack. Wine
glasses can be placed safely in the foldable aps by insert-
ing the stem of each glass into the corresponding slots.
LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc. Large
plates and lids should ideally be placed at the
sides to avoid interferences with the spray arm.
The lower rack has tip-up supports which can
be used in a vertical position when arranging
plates or in ahorizontal position (lower) to load
pans and salad bowls easily.
(loading example for the lower rack)
POWER CLEAN®
Power Clean® uses the special water jets in the
rear of cavity to wash more intensively the high
dirty items. The lower rack has aSpace Zone,
aspecial pull-out support in the rear of the rack that can be used to support
frying pans or baking pans in upright position, thus taking up less space.
Placing the pots/casseroles faced to the Power Clean® component please
activate the POWER CLEAN on the panel.
LOADING THE RACKS
CAPACITY: 15 standard place-settings
