Handleiding

Quick Guide

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

DELAY - The start time of the program may be delayed for a period of

time between 1 and 12 hours.

The DELAY function cannot be set once a wash cycle has been started.

POWER CLEAN® - Thanks to the additional power jets this option

provides a more intensive and powerful wash in the lower rack, in the

specic area. This option is recommended for washing pots and casseroles.

TABLET (Tab)- If you use powder or liquid detergent, this option

should be o.

MULTIZONE - If there are not many dishes to be washed, a half loading

may be used in order to save water, electricity and detergent.

Bydefault the appliance washes dishes in all racks.

OPERATION INDICATOR -

A LED light projected on the oor indicates

that the dishwasher is working.

One of the following operating modes can be selected:

a) Disabled function.

b) When the cycle starts the light goes on for few seconds, stays o during

the cycle and ashes at the end of the cycle.

c) The light stays on during the cycle and ashes at the end of the cycle

(default mode).

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address:

dw_test_support@europeanappliances.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

OPTIONS AND FUNCTIONS

Please scan the QR code on your product in order to have more detailed information.

EXTRA DRY - A higher temperature during the nal rinse and an

extended drying phase allow for improving drying.

NaturalDry

is a convection drying system which automatically opens the

door during/after drying phase to ensure exceptional drying performance

every day. Door opens at the temperature that is safe to your kitchen furniture.

LOADING THE RACKS

CAPACITY: 10 standard place-settings

CARE AND MAINTENANCE

More information in the Daily Reference Guide on website.

CUTLERY RACK

The third rack was designed to

house the cutlery.

(loading example for the cutlery rack)

UPPER RACK

Load delicate and light dishes: glasses, cups, sau-

cers, low salad bowls.

The upper rack has tip-up supports which can be

used in a vertical position when arranging tea/ des-

sert saucers or in a lower position to load bowls and

food containers.

(loading example for the upper rack

FOLDABLE FLAPS

WITH ADJUSTABLE

SITION

LOWER RACK

For pots, lids, plates, salad bowls, cutlery etc. Large

plates and lids should ideally be placed at the sides to

avoid interferences with the spray arm.

The lower rack has tip-up supports which can be used in

a vertical position when arranging plates or in a horizon-

tal position (lower) to load pans and salad bowls easily.

(loading example for the lower rack)

POWER CLEAN®

Power Clean® uses the special water jets in the rear of

cavity to wash more intensively the high dirty items. The

lower rack has a Space Zone, a special pull-out support in

the rear of the rack that can be used to support frying

pans or baking pans in upright position, thus taking up

less space.

Placing the pots/casseroles faced to the Power Clean® component please

activate the POWER CLEAN® on the panel.

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

1 2 3

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds

etc.) please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in

aclockwise direction.

The lower spray arm may be

removed by pulling it upwards.
