BURNER AND NOZZLE SPECIFICATIONS CATEGORY
II2H3+
Type of gas used Type of burner Injector marking Rated thermal
ow rate
kW
Rated
consumption
Reduced heat
capacity
kW
Gas pressure
mbar
min. rat. max.
NATURAL GAS
(Methane) G20
Semi-rapid (SR)
Auxiliary (AUX)
Mini Wok (MW)
95 Z
72 X
138 A
1,65
1,00
3,50
157 l/h
95 l/h
333 l/h
0,40
0,40
2,20
17 20 25
LIQUEFIED
PETROLEUM GAS
(Butane) G30
Semi-rapid (SR)
Auxiliary (AUX)
Mini Wok (MW)
63
50
93 P
1,65
1,00
3,50
120 g/h
73 g/h
254 g/h
0,40
0,40
2,20
20 28-30 35
LIQUEFIED
PETROLEUM GAS
(Propane) G31
Semi-rapid (SR)
Auxiliary (AUX)
Mini Wok (MW)
63
50
93 P
1,65
1,00
3,50
118 g/h
71 g/h
250 g/h
0,40
0,40
2,20
25 37 45
Type of gas used Model conguration
4 BURNERS
Rated thermal owrate
(kW)
Total rated consumption Air required (m
3
) for burning
1m
3
of gas
G20 20 mbar 2SR - 1AUX - 1MW 7,80 743 l/h 9,52
G30 28-30 mbar 2SR - 1AUX - 1MW 7,80 567 g/h 30,94
G31 37 mbar 2SR - 1AUX - 1MW 7,80 557 g/h 23,80
ELECTRIC SUPPLY: 220-240 V ~ 50-60 Hz - 0,6 W
BURNER AND NOZZLE SPECIFICATIONS
MT
CATEGORY
II2H3B/P
Type of gas used Type of burner Injector marking Rated thermal
ow rate
kW
Rated
consumption
Reduced heat
capacity
kW
Gas pressure
mbar
min. rat. max.
NATURAL GAS
(Methane) G20
Semi-rapid (SR)
Auxiliary (AUX)
Mini Wok (MW)
95 Z
72 X
138 A
1,65
1,00
3,50
157 l/h
95 l/h
333 l/h
0,40
0,40
2,20
17 20 25
LIQUEFIED
PETROLEUM GAS
(Butane) G30
Semi-rapid (SR)
Auxiliary (AUX)
Mini Wok (MW)
63
50
93 P
1,65
1,00
3,50
120 g/h
73 g/h
254 g/h
0,40
0,40
2,20
20 30 35
LIQUEFIED
PETROLEUM GAS
(Propane) G31
Semi-rapid (SR)
Auxiliary (AUX)
Mini Wok (MW)
63
50
93 P
1,65
1,00
3,50
118 g/h
71 g/h
250 g/h
0,40
0,40
2,20
25 37 45
Type of gas used Model conguration
4 BURNERS
Rated thermal owrate
(kW)
Total rated consumption Air required (m
3
) for burning
1m
3
of gas
G20 20 mbar 2SR - 1AUX - 1MW 7,80 743 l/h 9,52
G30 30 mbar 2SR - 1AUX - 1MW 7,80 567 g/h 30,94
G31 37 mbar 2SR - 1AUX - 1MW 7,80 557 g/h 23,80
ELECTRIC SUPPLY: 220-240 V ~ 50-60 Hz - 0,6 W
