1 “ON/OFF” button
2 Programme selector
3 “Start/Pause” button
4 “Spin” button
5 “Intensive rinse” button
6 “Clean+” button /
“Key lock“ button
7 “Start delay” button
8 “FreshCare+”
9 “Temperature” button
DISPLAY INDICATORS
Door locked
FreshCare+ activated
Start delay activated
Key lock activated
Washing phase
Indicates washing phase of the cycle
Failure: Call Service
Refer to Troubleshooting section
Failure: Water lter clogged
Water cannot be drained; water lter
might be blocked
Failure: No water
No or not sucient inlet water.
In the event of any failure, refer to the
“TROUBLESHOOTING” section
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.whirlpool.eu/register
CONTROL PANEL
PROGRAMME CHART
PRODUCT DESCRIPTION
1. Worktop
2. Detergent dispenser
3. Control panel
4. Door handle
5. Door
6. Water lter - behind plinth
7. Plinth (removable)
8. Adjustable feet (4)
1.
2.
7.
3.
4.
5.
6.
8.
DETERGENT DISPENSER
Main wash compartment
Detergent for the main wash, stain remover
or water softener. For a liquid detergent it
is recommended to use removable plastic
partition A (supplied) for a proper dosage. If
powder detergent is used, place the partition
into slot B.
Prewash compartment
Detergent for the prewash.
Softener compartment
Fabric softener. Liquid starch.
Pour in softener or starch solution only up to the “max” mark.
Release button
Press to remove tray for cleaning.
A
B
*
After programme end and spinning with maximum selectable spin speed, in default
programme setting.
**
The duration of the programme is shown on the display.
*** The display will show the suggested spin speed as default value.
6th Sense - the sensor technology adapts water, energy and programme duration to your
wash load.
This data may dier in your home due to changing conditions in inlet water temperature,
water pressure etc. Approximate programme duration values refer to the default setting of
the programmes, without options.
The values given for programmes other than the Eco 40-60
programme are indicative only.
Eco 40-60 - Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The
most ecient programme in terms of energy and water consumption for washing normally
soiled cotton laundry.
Note: spin speed values shown on the display can slightly diers from the values stated
in the table.
For all Test Institutes
Long wash cycle for cottons: set wash cycle Cotton with a temperature of 40°C.
Synthetic program along: set wash cycle Synthetics with a temperature of 40°C.
EN
User Manual
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bolts are removed.
For more detailed instructions on how to remove them, see the Installation Guide.
+1 +2 +3
3
1
2
21 53
9
4
7
8
6
Max load 9 Kg
Power consumption in o -mode 0.5 W / in left-on mode 8.0 W
Detergents and additives
Recommend-
ed detergent
Residual
dampness % (*)
Energy
consumption
kWh
Total water lt
Laundry
temperature °C
Programme
Temperatures
Max. spin
speed
(rpm)
Max
load
(kg)
Duration
(h : m)
Prewash
Main
wash
Softener
Powder
Liquid
Setting Range
Mixed (Gemengde was) 40°C
- 40°C
1000 9.0 ** –
–
– – – –
White
(Witte was) 60°C
- 90°C
1400 9.0 2:35
(90°)
55 1,790 89 55
Cotton
(Katoen) 40°C
- 60°C
1400 9.0 3:30 –
53 1,200 97 45
Eco 40-60 40 °C 40°C
1351 9.0 3:45 –
53 0,800 59 32
1351 4.5 2:50 –
53 0,480 52 29
1351 2.5 2:10 –
53 0,240 41 25
Sport 40°C
- 40°C
600 4.0 ** –
–
– – – –
Duvet
(Dekbedden) 30°C
- 30°C
1000 3.5 ** –
–
– – – –
Steam Refresh – – – 2.0 ** – – – – – – – – –
Spin & Drain
(Centrif. & Afpompen) – – 1400 9.0 ** – – – – – – – – –
Rinse & Spin
(Spoelen & Centrif.) – – 1400 9.0 ** – –
– – – – – –
Rapid 30’
(Snel 30’) 30°C
- 30°C
1200 (***) 4.5 0:30 –
–
71 0,178 37 27
20°C 20 °C
- 20 °C
1400 9.0 1:50 –
–
55 0,138 78 22
Wool
(Wol) 40°C
- 40°C
800 2.0 ** –
–
– – – –
Delicates
(Fijne was) 30°C
- 30°C
600 (***) 1.0 ** –
–
– – – –
Synthetics
(Synthetisch) 40°C
- 60°C
1200 4.5 2:15 –
35 0,580 60 43
Dosing required Dosing optional
