1 “ON/OFF” button
2 Programme selector
3 “Start/Pause” button
4 “Spin” button
5 “Intensive rinse” button
6 “Clean+” button /
“Key lock“ button
7 “Start delay” button
8 “FreshCare+”
9 “Temperature” button
DISPLAY INDICATORS
Door locked
FreshCare+ activated
Start delay activated
Key lock activated
Washing phase
Indicates washing phase of the cycle
Failure: Call Service
Refer to Troubleshooting section
Failure: Water lter clogged
Water cannot be drained; water lter
might be blocked
Failure: No water
No or not sucient inlet water.
In the event of any failure, refer to the
“TROUBLESHOOTING” section
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.whirlpool.eu/register
CONTROL PANEL
PROGRAMME CHART
PRODUCT DESCRIPTION
1. Worktop
2. Detergent dispenser
3. Control panel
4. Door handle
5. Door
6. Water lter - behind plinth
7. Plinth (removable)
8. Adjustable feet (4)
1.
2.
7.
3.
4.
5.
6.
8.
DETERGENT DISPENSER
Main wash compartment
Detergent for the main wash, stain remover
or water softener. For a liquid detergent it
is recommended to use removable plastic
partition A (supplied) for a proper dosage. If
powder detergent is used, place the partition
into slot B.
Prewash compartment
Detergent for the prewash.
Softener compartment
Fabric softener. Liquid starch.
Pour in softener or starch solution only up to the “max” mark.
Release button
Press to remove tray for cleaning.
A
B
* After programme end and spinning with maximum selectable spin speed, in default
programme setting.
** The duration of the programme is shown on the display.
*** The display will show the suggested spin speed as default value.
6th Sense - the sensor technology adapts water, energy and programme duration to your wash load.
This data may dier in your home due to changing conditions in inlet water temperature,
water pressure etc. Approximate programme duration values refer to the default setting of
the programmes, without options.
The values given for programmes other than the Eco 40-60
programme are indicative only.
Eco 40-60 - Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The most efficient
programme in terms of energy and water consumption for washing normally soiled cotton laundry.
Note: spin speed values shown on the display can slightly differs from the values stated in the table.
For all Test Institutes
Long wash cycle for cottons: set wash cycle Cotton with a temperature of 40°C.
Synthetic program along: set wash cycle Synthetics with a temperature of 40°C.
EN
Quick guide
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bolts are removed.
For more detailed instructions on how to remove them, see the Installation Guide.
+1 +2 +3
3
1
2
21 53
9
4
7
8
6
Max load 11 Kg
Power consumption in o -mode 0.5 W / in left-on mode 8.0 W
Detergents and additives
Recommended
detergent
Residual
dampness % (*)
Energy
consumption
kWh
Total water lt
Laundry
temperature °C
Programme
Temperatures
Max. spin
speed
(rpm)
Max
load
(kg)
Duration
(h : m)
Prewash
Main
wash
Softener
Powder
Liquid
Setting Range
Mixed (Variada)
40°C
- 40°C
1000 11.0 ** –
–
– – – –
White (Blanca)
60°C
- 90°C
1400 11.0 2:40
(90°)
54 1,900 100 55
Cotton (Algodón)
40°C
- 60°C
1400 11.0 3:55 –
49 1,140 107 45
Eco 40-60
40 °C 40°C
1351 11.0 4:00 –
53 0,780 75 31
1351 5.5 3:00 –
53 0,460 55 29
1351 3.0 3:00 –
53 0,220 35 24
Sport (Deporte)
40°C
- 40°C
600 4.5 ** –
–
– – – –
Duvet (Edredón)
30°C
- 30°C
1000 3.5 ** –
–
– – – –
Steam Refresh
– – – 2.0 ** – – – – – – – – –
Spin & Drain (Centrifugado y
desagüe)
– – 1400 11.0 ** – – – – – – – – –
Rinse & Spin (Aclarado y centrif.)
– – 1400 11.0 ** – –
– – – – – –
Rapid 30’ (Rápido 30’)
30°C
- 30°C
1200 (***) 5.5 0:30 –
–
71 0,210 50 27
20°C
20 °C
- 20 °C
1400 11.0 1:50 –
–
55 0,200 95 22
Wool (Lana)
40°C
- 40°C
800 2.5 ** –
–
– – – –
Delicates (Delicados)
30°C
- 30°C
600 (***) 1.0 ** –
–
– – – –
Synthetics (Sintéticos)
40°C
- 60°C
1200 5.5 2:55 –
35 0,830 80 43
Dosing required Dosing optional
