Specifications
Model
Model
DIAMOND 12.3 DIAMOND 12.4 DIAMOND 12.C
General description
Design philosophy and core technology
Enclosure type
Transducer complement
ABR
Bass driver
Midrange driver
Treble driver
Full-range driver
AV shield
Sensitivity(2.83V @ 1m)
Recommended amplifier power
Peak power handling
Peak SPL
Nominal impedance
Minimum impedance
Frequency response(+/-3dB)
Bass extension(-6dB)
Crossover frequency
Cabinet Volume (in litres)
Dimensions ( H x W x D )
Net weight
DIAMOND 12.0
2-way bookshelf speaker
bass reflex
2-way
4"(100mm) advanced PP Cone
1"(25mm) Textile Dome
No
87dB
20-60W
95dB
8Ω Compatible
4.0Ω
70Hz ~ 20kHz
65Hz
2.7kHz
4.4L
265 x 160 x (200+28) mm
5.1kg/pcs
DIAMOND 12.1
2-way bookshelf speaker
bass reflex
2-way
5"(130mm) advanced PP Cone
1"(25mm) Textile Dome
No
88dB
20-100W
96dB
8Ω Compatible
4.0Ω
65Hz ~ 20kHz
60Hz
2.6kHz
8.2L
312 x 180mm x (250+28) mm
6.8kg/pcs
DIAMOND 12.2
2-way bookshelf speaker
bass reflex
2-way
6.5"(150mm) advanced PP Cone
1"(25mm) Textile Dome
No
88dB
20-120W
96dB
8Ω Compatible
4.0Ω
50Hz ~ 20kHz
43Hz
2.0kHz
11.8L
335 x 200 x (285+28) mm
8.2kg/pcs
General description
Design philosophy and core technology
Enclosure type
Transducer complement
ABR
Bass driver
Midrange driver
Treble driver
Full-range driver
AV shield
Sensitivity(2.83V @ 1m)
Recommended amplifier power
Peak power handling
Peak SPL
Nominal impedance
Minimum impedance
Frequency response(+/-3dB)
Bass extension(-6dB)
Crossover frequency
Cabinet Volume (in litres)
Dimensions ( H x W x D )
Net weight
2.5-way floorstanding speaker
bass reflex
`
5"(130mm) advanced PP Cone
5"(130mm) advanced PP Cone
1"(25mm) Textile Dome
No
89dB
30-150W
102dB
8Ω Compatible
5.0Ω
45Hz ~ 20kHz
40Hz
2.2kHz
26.6L
(925+50) x 180 x (320+28) mm
19.5kg/pcs
2.5-way floorstanding speaker
bass reflex
`
6.5"(150mm) advanced PP Cone
6.5"(150mm) advanced PP Cone
1"(25mm) Textile Dome
No
89dB
30-200W
102dB
8Ω Compatible
5.0Ω
40Hz ~ 20kHz
35Hz
2.1kHz
40.8L
(1100+50) x 200 x (350+28) mm
22.4kg/pcs
2-way centre speaker
closed-box system
2-way
5"(130mm) advanced PP Cone x2
1"(25mm) Textile Dome
No
90dB
20-120W
96dB
8Ω Compatible
4.0Ω
90Hz ~ 20kHz
80Hz
2.2kHz
8.7L
180 x 480 x (180+28) mm
8.5kg/pcs
DIAMOND 12 3D SURROUND
2-way atmos speaker
closed-box system
2-way
4"(100mm) advanced PP Cone
1"(25mm) Textile Dome
No
82dB
20-100W
95dB
8Ω Compatible
4.3Ω
110Hz ~ 20kHz
90Hz
3kHz
2.7L
145 x 180 x 310 mm
3.2kg/pcs
11
