9
EN
6. You may now need to fine-tune the installation by
repeating steps 3, 4 and 5.
7. When you have the appliance in its final position, it
needs to be stabilised. Wind the stability foot under
the door hinge down to the floor until it just makes
contact with the floor. Lift the front of the appliance
to take the weight o the stability foot, then turn it
half a turn further to ensure firm contact with the
floor. Wind the large height adjusting nut back up to
ensure all the weight is now on the front stability
foot. Wind the large height adjusting nut back up to
ensure all the weight is now on the front stability
foot.
stability foot
wound down
Front view
8. Repeat step 7 for the stability foot on the handle
side. Whenever you need to move the appliance,
be sure to wind the feet back up so that the
appliance can roll freely and be sure to reset it when
reinstalling.
9. Plug your refrigerator straight into its own power
point and never use a double adapter. If you need to
roll the refrigerator to get to the plug, remember to
raise the stability foot first.
10. Before you put any food in your refrigerator,
it’s recommended you leave it on for 2 or 3 hours to
check it is running properly.
DOOR OPENING
Your refrigerator should be positioned to allow easy
access to a counter when removing food. For best
use of refrigerator drawers and freezer baskets, the
refrigerator should be in a position where both door
can be fully opened.
WARNING
LED lighting
Your appliance is fitted with long life
LED lighting. In the unlikely event the
LED lights should fail, then the LED lights
should be serviced by the service agent,
to avoid a safety hazard. Refer to the
warranty page for contact details.
INSTALLING YOUR REFRIGERATOR
1. Roll the refrigerator into place.
The rollers are designed for forward or backward
movement only. They are not castors. Moving the
refrigerator sideways may damage your floor and
the rollers. Before moving your refrigerator ensure
height adjusting nut and the stability foot
are fully wound up o the floor.
2. Stability foot adjusting nut under door hinge down
until the refrigerator is tilted back by 10mm (see
diagram).
Height
adjusting
nut
Fixed rear rollers
10-15mm
3. Stability foot adjusting nut on the handle side down
until the refrigerator is level and stable. If you have
diculty winding the nut or height adjusting foot
down (recommend 20 mm wrench), have someone
tilt the refrigerator back so you have better access.
stability foot
wound up
4. Check the alignment of the refrigerator to the
surrounding cupboards to see if it is level. You can
adjust the level as detailed in step 2 and 3.
aligned to
cupboards
i.e.,
even gap
top of refrigerator
is level i.e.,
horizontal
adjust front feel
for unevenness
of floor i.e.,
wind this foot
down or up
5. If you find your refrigerator rocks from corner to
corner, it means your floor is uneven. Find a piece
of plastic or hardboard etc. and pack it firmly under
the roller.
