21
EN
6. CONNECTING THE WATER SUPPLY
WARNING
Connect to potable water supply
only. If using tank or bore water it is
recommended to also use an external
filter (not supplied).
The new hose-sets supplied with the appliances must
be used and old hose-sets should not be reused.
Never connect the appliance to a hot water supply.
Do not use with water that is microbiologically unsafe
or with water of unknown quality without adequate
disinfection.
WATER FILTER
It should not be used on water that is micro biologically
unsafe or with water of unknown quality. The service
life of the filter may be reduced in water supplies that
contain an excess of particles or other impurities.
Reduced flow rate is an indication that a new filter is
required. Failure to replace the filter when required
can aect the function of the ice maker. Service calls
caused by a failure to replace the filter are not covered
by warranty. Replacement water filters are available
from Electrolux Home Products Spare Parts Centres
and can be posted to you for your convenience (refer to
spare parts contact numbers on the warranty page).
Note: A backflow prevention device compliant to AS/
NZS 2845.1 for low hazard situations must be installed
upstream of the connection in accordance to NCC
volume 3.
Contents of installation kit
4 metres of water tubing 1 x 1/2” tap fitting
WATER SUPPLY AND PLUMBING
A drinkable water supply to suit a 1/2” tap fitting
is required adjacent to the refrigerator. It is
recommended that a licensed plumber install a new
water supply outlet nearer to the appliance should
the tubing supplied not be long enough. It is not
recommended that the tubing be extended as this
could adversely aect the flow of water to the ice
maker or water dispenser. If there is a risk of flow rate
higher than the maximum flow rate 2.46 L/min, a flow
controller should be installed. The water dispenser and
automatic ice maker require a drinkable water supply
with a pressure range of between 206kPa and 689kPa
(30psi and 100psi). If the water supply is above 100psi
a pressure limiting valve should be installed.
It is recommended that a noise reduction valve also be
fitted in the water supply line. This will reduce water
hammer and its eects from quick action household
taps and fast acting valves on appliances.
The refrigerator water valve is pre-fitted with a
push-fit connector for inserting the water tube. When
the tap connection is other than 1/2”, adapters can
be purchased from plumbing supply stores or good
hardware stores.
Please read before beginning installation.
The appliance complies with the relevant backflow
prevention requirements specified in AS/NZS 2845.1.
The water connection to your ice and water product
can be self installed. However, it is recommended
that you seek advice from a licensed plumber before
commencing the installation.
IMPORTANT
Check for water leaks at all water
connection points in the first 2 to 3
hours after installation, and correct
it in case of any water leak. Recheck
after 24 hours; if leak still occurs, it is
recommended to contact a licensed
plumber for advice.
Water is to be connected as per diagram below.
sink
mains
water
inlet
kitchen cupboard
½" tap
fitting
Step 1 Ensure that the refrigerator is disconnected
from power supply.
Step 2 Connect tap fitting to water supply tap. Tap
must be close to the refrigerator.(only hand tighten)
Step 3 Push the tube into tap fitting past insertion
mark.
