English | 11
ASSEMBLY
lThe window vent kit can be modied to t different sized
windows that open vertically or horizontally up to 39.9 in.
• If the window opening is less than 20.5 in., use a saw
to cut the xed panel to the appropriate size.
• If the window opening is larger than the xed panel
(20.5 in.), use sliding panels. Secure additional pan-
els using screws.
lInstall the window vent kit into the window frame.
A - Foam Seal (Adhessive)
B - Height
A - Hose Outlet
FIG. 10
A
B
A - Fixed Panel
B - Sliding Panel
C - Screw
FIG. 11
FIG. 12
FIG. 15
FIG. 14
C
B
A
HORIZONTAL INSTALLATION
FIG. 13
VERTICAL INSTALLATION
A
lPlace the foam seal (non-adhessive type) between the
glass and the window frame to prevent air and insects
from getting into the room.
lInsert the hose outlet into the opening in the xed panel.
NOTE: When the hose outlet is disconnected, cover the
opening.
A - Foam Seal (Non-adhessive)
A
