Specifications

- 13 -

2.2.1 Physical Dimensions

2.3 Mechanical Specifications

Figure 2-1 shows the mounting dimensions and locations of the screw holes for the

drive.

Note: Unless otherwise specified, all measurements are in millimeters.

Figure 2-1. Mounting Dimensions

Table 2-3. Physical Dimensions

English Metric

Dimension Tolerance Dimension Tolerance

Height 1.028 inches MAX 26.1 mm MAX

Length 5.787 inches MAX 147.0 mm MAX

Width 4.00 inches ±0.01 inch 101.6 mm ±0.25 mm

Weight 1.58 pounds MAX 0.715 kg MAX
