80” Long Deck Scissors Lift Tables
(Part # 273230)
Operating Instructions and Parts Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO LIFT TABLE, READ THESE INSTRUCTIONS BEFORE USING.
REPLACEMENT PART INFORMATION
Frame Part List
Item P/N Description Qty
Item P/N Description Qty
1 Table 1
20 273722 Caster: Rigid, 7” x 2” Nylon 2
2 Screw 1
21 Frame 1
3 Fork Arm 1
22 Screw 2
4 Roller of Table 2
23 Plate 2
5 Locking Ring 4
24 273758 Pin 2
6 273720 Hydraulic Pump 1
25 Roller 2
7 Locking Ring 2
26 Axle 1
8 273759 Pedal Bar 1
27 Shaft 1
9 Shaft 1
28 Elastic Pin 1
10 Bolt 4
29 273723 Handle (With Release Lever & Cables) 1
11 Bolt 2
30 Elastic Washer 4
12 Elastic Washer 2
31 Shaft 1
13 Cover 2
32 273721 Caster: Locking, Swivel 7” x 2” Nylon 2
14 Bearing 2
33 Locking Washer 2
15 273724 Bearing 2
34 Nut 2
16 273725 Housing: Swivel Caster 2
35 Dust Cover 2
17 273726 Axle: Swivel Caster 2
36 Nut 4
18 Washer 4
37 273756 Control Handle 1
19 273727 Bearing 8
A 273757 Assembly: Caster 2
