ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO HIGH LIFT
TRUCK, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
5. PUMP ASSEMBLY INFORMATION
5.2 PUMP ASSEMBLY PARTS LIST
WESCO
Replacement P/N
No. Description Quantity
WESCO
Replacement P/N
No. Description Quantity
71 Washer 1
147 Sealing Screw 1
72 Spring 1
148 Screw 1
172336 73 Bushing 2
149 Snap Ring 1
272903 74 Washer 1
SEAL KIT ONLY 150 O-Ring 2
75 Gasket 1
SEAL KIT ONLY 153 O-Ring 1
172273 104 Pin 1
SEAL KIT ONLY 155 O-Ring 1
172274 105 Roller 1
157 Screw 1
172280 111 Washer 1
172302 158 Air Screw 1
172281 112 Pendulum Arm 1
159 Cylinder 1
172286 117 Pin 1
160 Pump Housing 1
172287 118 Valve Insert 1
172303 161 Thrust Bearing 1
172288 119 Seat 1
172304 162 Ball 1
272848 Kit:
Release
Mechanism
172289 120 Screw 2
172305 163 Snap ring 1
172290 121 Gasket 2
172306 164 Washer 1
172291 122 Spring 2
172312 170 Bush 2
172292 123 Release Valve 2
171 Piston 1
172293 124 Ball 2
172313 172 Screw 1
172294 125 Valve Insert 1
172314 173 Axle 1
172295 126 O-Ring 8
172315 174 Gasket 1
172296 127 Spring 1
172316 175 Lock Screw 1
172297 128 O-Ring 1
172317 176 Rubber Sleeve 1
172298 129 Release Indicator 1
172318 177 Washer 1
172299 130 Screw 1
172321 180 Adjusting Screw 1
CYL./PISTON KIT 131 Pump Piston 1
172322 181 Handle Base 1
SEAL KIT ONLY 132 Guide Ring 1
172323 182 Adjusting Washer 1
SEAL KIT ONLY 133 Y-Ring 1
172324 183 Rubber Sleeve 1
270676 134 Washer 1
172325 184 Spring Guide 1
270677 135 Snap Ring 1
190
Copper Piston 1
SEAL KIT ONLY 136 Scraper Ring 2
172331
191
Snap Ring 1
SEAL KIT ONLY 137 O-Ring 2
172332 192 Snap Ring 2
SEAL KIT ONLY 138 Y-Ring 2
SEE TABLE ON
PAGE 9
300 Pump Unit 1
CYLINDER/PISTON
KIT ONLY
139 Pump Cylinder 1
172450
(For 272749
Pump Only)
301 Bushing 1
SEAL KIT ONLY 140 O-Ring 1
SEAL KIT ONLY 302 Back-Up Ring 1
270471 141 Spring 1
SEAL KIT ONLY 303 Y-Ring 1
270679 142
Hi-Pressure
Piston
1
172451
(For 272749
Pump Only)
304 Bushing 1
SEAL KIT ONLY 143 O-Ring 2
305 Snap Ring 1
144 Ball 1
306 Piston Rod 1
145 Spring 2
307 Cylinder Head 1
146 Adjusting Screw 2
308
Lifting Ram 1
NOTE: Items within kits specify quantity included per kit
Telescoping Manual High Lift Truck
(Part # 272754, 272755, 272975 & 272976)
Instruction Manual
