Folding Handle Scissor Lift Tables
(Part # 272974)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO SCISSOR LIFT
TABLE, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
6. PART INFORMATION
6.2 FRAME PARTS LIST
Item P/N Description Qty.
No. P/N Description Qty.
101 Handle Grip 1
131 Washer 2
102
Kit:
Release
Assembly
272977
Control Handle 1
132 Retaining Ring 2
103 Elastic Pin 1
133 Connecting Rod 1
104 Nut 1
134 Cushion 1
105 Bolt with Hole 1
135 Bolt 1
106 Jacket 1
136 Washer 1
107 Pull Rod 1
137 Elastic Washer 1
108 Bolt 12
138 Nut 1
109 Washer 12
139 Protecting Cover 1
110 Seat of Grip 2
140 Pedal Bar 1
111
Retaining Ring 6
141
Table 1
112
Pin 4
142
Retaining Ring 4
113
Elastic Washer 12
143
Roller 2
114
Nut 12
144
Washer 4
115
Spring 2
145
Roller 2
116
Cushion 2
146
Pin 2
117
Long Shaft 1
147
Bushing 2
118
151543 Universal Wheel 2
148
Retaining Ring 2
119
Frame 1
149
Pin 1
120
Pin 2
150
Retaining Ring 2
121
Washer 4
151
Fork Arm 1
122
Axle 2
152
Bushing 2
123
Bearing 4
153
Pin 2
124
151542 Wheel 2
154
Retaining Ring 2
125
Retaining Ring 2
157
Support Plank 2
126
151544 Pump Unit 1
158
Nut 2
127
Pin 1
159
Screw 2
128
Washer 1
160
Protecting Board 1
129
Retaining Ring 1
161
Bolt 4
130
Pin 1
