Heavy Duty Scissors Lift Tables
(Part # 272970 & 272973)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR SCISSORS LIFT TABLE,
READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
6. 272970 PART INFORMATION
6.2 272970 FRAME PART LIST
Item P/N Item Description Qty.
Item P/N Item Description Qty.
101M 260261 Handle Grip 1
134 Bolt 1
102
Kit:
Handle
Release
Assembly
260253
Control Handle 1
135 Shaft 1
103 Elastic Pin 1
136 Retaining Ring 1
104 Nut 1
137 Axle of Wheel 1
105 Bolt with Hole 1
138G Pump Unit 1
106 Jacket 1
139 260265 Pin 1
107 Pull Line 1
140 260266 Roller 1
108 Elastic Pin 1
141 260267 Retaining Ring 1
109 Shaft 1
142 Pin 1
110 Cam 2
143 Washer 1
111 Pedal 1
144 Retaining Ring 1
112 Screw 3
145 260268 Connecting Rod 1
113 Nut 3
146 Cushion 1
114 260262 Big Washer 2
147 Bolt 1
115 260263 Elastic Washer 2
148 Washer 1
116 260264 Bolt 2
149 Elastic Washer 1
117 Bolt 2
150 Nut 1
118 Nut 2
151 Protecting Nut 1
119 Round Nut 4
152 Pedal Bar 1
120 Spring 2
153 Retaining Ring 1
121
Kit:
Caster
Assembly
260256
Seat of Wheel 2
154 Roller 1
122 Bolt 2
155 Roller 1
123 Brake 2
156 Table 1
124 Washer 4
157 Retaining Ring 1
125 Bearing 8
158 Shaft 1
126 Wheel 4
159 Fork Arm 1
127 Axle 2
160 Elastic Washer 1
128 Elastic Washer 2
161 Screw 1
129 Nut 2
162 Screw 1
130 Bearing 2
163 Nut 1
131 Washer 2
164 Support Plank 1
132 Bearing 2
165 Elastic Pin 1
133 Frame 1
REPLACEMENT KITS OFFERED
260253 Handle Release Assembly (Includes items 102-107) 1
260256 Caster Assembly (Includes Items 121-129) 2
260257 Wheel Assembly (Includes 2 of Item 125 & 1 of Item 126) 2
