Heavy Duty Scissors Lift Tables
(Part # 272970 & 272973)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR SCISSORS LIFT TABLE,
READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
7. 272973 PART INFORMATION
7.4 272973 PUMP PART LIST
Item P/N Item Description Qty.
Item P/N Item Description Qty.
273632 Complete Pump Replacement 1
230 Spring 1
201 Seal Washer 1
231 Spindle of Safety Valve 1
202 Pump Cylinder 1
232 Steel Ball 1
203 Dust Ring 1
233 O-Ring 1
204 Y-Seal 1
234 Seat of Pumping Valve 1
205 Pump Piston 1
235 Spindle of Pumping Valve 1
206 Spring 1
236 Spring 1
207 Spring Cap 1
237 Seal Washer 1
208 Retaining Ring 1
238B O-Ring 1
209B Joint Plate 2
239G Seal Washer 1
210 Pin 1
240G Cylinder 1
211G Pump Body 1
241B Housing 1
212 Elastic Pin 1
242 Bolt 1
213 Spring 1
243 Seal Washer 1
214B Strike pin 1
244 Retaining Ring 1
215 Seal Washer 1
245G Washer 1
216B Axle Sleeve 1
246G Y-Seal 1
217 O-Ring 2
247 1
218 Nut 1
248G Piston 1
219 Screw 1
249G O-Ring 1
220 Lever Plate 1
250G Piston Rod 1
221 Nut 1
251B O-Ring 1
222 Elastic Washer 1
252G Cylinder Cap 1
223 Washer 1
253G O-Ring 1
224 Bolt with Hole 1
254G Dust Ring 1
225 Bolt with Hole 1
255B Plug 1
226 Nut 1
256 Liquid Throttle 1
227 Plug 1
257 Bolt 1
228 O-Ring 1
258B O-Ring 2
229 Adjusting Bolt 1
