ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO HIGH LIFT
TRUCK, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
9. PUMP ASSEMBLY INFORMATION
9.4 PUMP ASSEMBLY PARTS LIST
(UNITS MANUFACTURED BETWEEN 08/2010 & 06/2015)
No.
WESCO
Replacement
P/N
Description Qty.
No.
WESCO
Replacement
P/N
Description Qty.
101 270684 Spacer 2
172 270329 Screw
1
103 270685 Washer 2
176 270323 Rubber Sleeve
1
105 270140 Tension Spring 1
190 270332 Copper Piston
1
108 270286 Pin 1
191 270333 Snap Ring
1
109 270686 Nut 2
192 270334 Snap Ring
1
110 270302 Adjusting Screw 1
195 270336 Washer
1
111 270304 Snap Ring 2
198 270588 O-Ring
2
112 270305 Sleeve 2
199 270589 Bushing
1
113 270306 Pin 1
200 270617 Cylinder
1
136
Scraper Ring 1
201 270618 Back-Up Ring
1
137 270308 O-Ring 1
201 270618 Back-Up Ring
1
138 270309 Y-Ring 1
400 Bronze Bushing
1
153 270310 O-Ring 1
401 Back-Up Ring
1
154 270311 Cylinder Head 1
402 Y-Ring
1
155 270315 Bushing 1
403 Bushing
1
156 270316 Cylinder 1
404 Snap Ring
1
157 270317 Plate 1
405 Bushing
2
160 270318 Pump Housing 1
406 270892 Piston Rod
1
161 270319 Thrust Bearing 1
412 Cylinder Head
1
162 270320 Ball 1
413 Cylinder
1
163 270321 Snap Ring 1
414 Snap Ring
1
164 270322 Washer 1
419 Snap Ring
1
165 270323 Bronze Bushing 1
420 Bushing
2
166 270659 Piston Rod 1
424 O-Ring
1
167 270325 O-Ring 1
422 Piston
1
169 270326 Y-Ring 1
423 Back-Up Ring
1
170 270327 Washer 1
424 Y-Ring
1
171 270328 Piston 1
300 270654 Replacement Pump
1
SEAL
KIT
*270477
Seal Kit (Includes items 136, 137, 138, 153, 198 [2], 201, 401, 402, 420 [2],
421, 423, 424)
1
NOTE: Items within kits specify quantity included per kit
**Seal Kit for Units Manufactured Between 08/2010 & 06/2015 Only.
