Scale Pallet Truck
(Part # 272936 & 272938)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO PALLET
TRUCK, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
WARNING: The battery in this product contains lead. The State of California under
Proposition 65 has determined that exposure to lead is known to cause cancer or birth
defects or other reproductive harm. Please wash hands after use.
1. GENERAL INFORMATION
1.1 DESCRIPTION
Thank you for purchasing a Wesco Scale Pallet Truck. This pallet truck is designed for
transporting and horizontal lifting. The pallet truck features a 2 year pump warranty, and a LED
display scale with a weighing accuracy of ±.4.4 lbs, or 2 kg. It operates with 7” moldon polyurethane
or nylon steering wheels and 3” moldon polyurethane or nylon load wheels.
1.2 SPECIFICATIONS
Model 272936 272938
Capacity 5,000 lbs 5,000 lbs
Weight 336 lbs 314 lbs
Fork Lowered Height 2.9” 2.9”
Fork Raised Height 8” 8”
Single Fork Width 7” 7”
Fork Length 47.5” 47.5”
Overall Width 27.5” 22.5”
Overall Length 62.5” 62.5”
Overall Height 48.25” 48.25”
Steering & Load Wheels Polyurethane Polyurethane
Materials and specifications are subject to change without notice.
2. PRE-OPERATION ASSEMBLY
Note: Before use, the truck should be charged overnight for optimal performance.
2.1 ATTACHING DISPLAY UNIT (230)
1) Remove 4 pcs bolts (233) from the fork frame (218).
2) Remove 4 pcs bolts (237), then take away the cover board (231)
3) Set the fixation box (232) onto the head of pallet truck with one hand, and with the other hand
take the cable
outthedoorofthefixationbox(232).
4)
Tighten4pcsbolts(233)securely.
5)
Openthecoverofbattery;fixbatterypackinbatterycompartmentwithvelcroasshownonpage4.
6)
Connectthecableto the display unit (230).NOTE:The connectport is onthe back‐left side of the
displayunit.
7)
Coverthecoverboard231,thentighten4pcsbolts(237)securely.
Thedisplayunitisnowfixed.
