159272A Page 15 of 18
© Copyright 2018 WESCO Industrial Products, LLC. Specifications subject to change. Not responsible for errors or omissions.
Scale Pallet Truck
(Part # 272936 & 272938)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO PALLET
TRUCK, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
9. FRAME INFORMATION
9.2 FRAME PARTS LIST
IND221 IND231
WESCO P/N No. Description
Qty for Units
Before
05/2007
Qty fo
r
Units After
05/2007
Qty fo
r
Units After
03/2015
270151 201 Fork Frame 1 1 1
270159 202 Oil-Holder 1 1 1
270160 203 Rock - Arm 1 1 1
270164 204 Elastic Pin 9 9 9
270172 205 Retaining Ring 4 4 4
270174 206 Joint 2 2 2
270178 207 Shaft 2 2 2
270179 208 Pushing Rod 2 2 2
270180 209 Nut 2 2 2
270181 210 Pin 2 2 2
270182 211 Long Shaft 1 1 1
270183 212 Shaft 2 2 2
270184 213 Elastic Pin 2 2 2
270185 214 Shaft 2 2 2
270186 215 Frame of Roller 2 2 2
270187 216 Elastic Pin 2 2 2
270189 217 Shaft of Roller 4 4 4
270190 218 Fork Frame 1 1 1
270191 219 Washer 8 8 8
270193 220 Bearing 8 8 8
270194 221 Roller 4 4 4
270195 222 Linking Plate 4 4 4
270197 223 Platform 1 1 1
270198 224 Bolt 2 2 2
270199 225 Load Pad 4 4 4
270200
Kit: Pin/O-Ring
226 Pin 4 4 4
227 O-Ring 8 8 8
270202 228 Bolt 4 8 8
270204 229 Set Of Load Cells (
w
ith Junction Box) 1 1 1
270205 230 Display Unit 1 Not Used Not Used
270206 231 Cover Board 1 Not Used Not Used
270207 232 Fixation Box 1 Not Used Not Used
270209 233 Bolt 4 Not Used Not Used
270210 234 Box of Cable 1 1 1
270212 235 Nut 2 2 2
270215 236 Screw 2 2 2
270216 237 Bolt 4 Not Used Not Used
270224 Motherboard of Display 1 Not Used Not Used
270395 247-7 Display Unit Not Used 1 1
272850 247-8 Bolt Not Used 2 2
Battery
Arrangement
272851
**247-9
Charging Plug for IND 221 Not Used 1 Not Used
273167 Charging Plug for IND 231 1
2 Rows of 3 272849 247-10
Battery
(For IND 221)
Not Used 1
1 Rows of 6 270793
Rechargeable Battery
(For IND231)
Not Used Not Used 1
6 “D” Cell 172180
Battery
(For Units Before 05/2007)
1 Not Used Not Used
272852 247-11 Plug Not Used 1 1
270277 AC Adapter 1 Not Used Not Used
*Items within kits specify quantity included per kit
** Charging plug details shown on page 16.
