Scale Pallet Truck
(Part # 272936 & 272938)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO PALLET
TRUCK, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
8. HANDLE INFORMATION
8.2 HANDLE PARTS LIST
WESCO Replacement P/N No. Description Qty.
270060:
Handle Release Assembly
101 Release Rod 1
102 Chain 1
103 Adjusting Bolt 1
104 Adjusting Nut 1
270004
Kit: Axle/Pin
105 Axle with Hole 1
106 Elastic Pin 2
273008 107 Bushing 2
270005
Kit: Pressure Roller
108 Roller Pin 1
109 Pressure Roller 1
109A Bushing 1
270007
Kit: Handle Assembly
273505
101 Release Rod 1
102 Chain 1
103 Adjusting Bolt 1
104 Adjusting Nut 1
107 Bushing 2
108 Roller Pin 1
109 Pressure Roller 1
109A Bushing 1
110 Draw-bar 1
111 Stop Rubber 1
112 Elastic Pin 1
113 Blade Spring 1
114 Spring 1
115 Elastic Pin 1
116 Elastic Pin 1
272791
Kit: Control Handle
117 Control Handle 1
118 Roller 1
119 Elastic Pin 1
*Items within kits specify quantity included per kit
