Page15of15
©Copyright2018WESCOIndustrialProducts,LLC.Specificationssubjecttochange.Notresponsibleforerrorsoromissions.
Electric Office Lift
(Part # 272468)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO LIFTER, READ
THESE INSTRUCTIONS ENTIRELY BEFORE USING.
9. PART INFORMATION (UNITS MANUFACTURED BEFORE JUNE 2014)
9.4 ELECTRICAL BOX PART LIST
Item P/N Description Qty. Item P/N Description Qty.
201 273072 (Storage) Battery 2
218 273176 Transmission Chain Wheel 1
202 KIT B Nut 1
219 KIT B Top Fixing Bolt 3
203 KIT B Capacity Adjust Bolt 1
220 273175 Transmission Shaft 1
204 Spring 1
221 273174 Interval Ring 1
205 Adjustable Bolt 1
222 273177 Plain Pin 2
206 273073 Charger 1
223 273173 Big Chain Wheel 1
207 273074 Circuit Board 1
224 Motor Chain Wheel 1
208 KIT B Hex Bolt 2
225 273170 Motor Seat 1
209 273178 Traveling Switch 2
226 273172 Bearing 2
210 Traveling Switch Seat 1
227 273171 Bearing Lid 2
211 KIT B Nut 2
228 Plain Pin 1
212 Flexible Racket 1
229
273179 Motor 1
213 Bush 1
For Units Manufactured Before 12/2014)
214 Oil-Free Bearing 1
273185 Motor 1
215 Sunk Bolt 1
(For Units Manufactured After 12/2014)
216 Flexible trolley 1
230 Electric Box Lid 1
217 273180 Pull Spring 1
231 273134 Link Chain 1
REPLACEMENT KIT LIST
Kit Item P/N Description Qty.
A 273071 HARDWARE KIT 1
11
Sunk Bolt 2
15
Sunk Bolt 4
22
Sunk Bolt 2
28
Inner Hex Bolt 4
30
Hex Nut M8 x 1.25 1
40
Nut 1
43
Hex Bolt 4
46
Hex Bolt 2
202
Shown
on Page
14
Nut 1
203 Capacity Adjustment Bolt 1
208 Hex Bolt 2
211 Nut 2
219 Top Prick Fixing Bolt 3
Note: Items within kits specify quantity included per kit
