©Copyright 2015 WESCO Industrial Products, Inc. Specifications subject to change. Not responsible for errors or omissions.
Manual Non-Telescoping High Lift Truck
(Part # 272462 & 272463)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO HIGH LIFT
TRUCK, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
4. FORK FRAME INFORMATION
4.2 FORK FRAME PARTS LIST
WESCO
Replacement
P/N
No. Description Quantity
WESCO
Replacement
P/N
No. Description Quantity
272753
01
Front Wheel
(For Models Before
12/2009 and After 2014)
2
29 Nut 2
30 Pin 2
273728
Front Wheel
(For Models Between
2010 and 2014)
2
31 Snap Ring 2
32 Pin 2
272638
02
Ball Bearing
(For Models Before
12/2009 and After 2014)
8
33 Screw 2
34 Bush 2
272489
Ball Bearing
(For Models Between
2010 and 2014)
8
35 Handle Tube 1
36 Nut 1
03 Washer 6 37 Eye Bolt 1
04 Snap Ring 16 38 Chain 1
05 Pin 2 39 Chain Connector 3
06 Leg 2 40 Release Rod 1
07 Screw 2 41 Screw 6
08 Washer 2 42 Cover 1
09 Washer 2 43 Pin 6
10 Ball Bearing 4 44 Pin 1
11 Leg 1 45 Ball 1
12 Centrifugal Axle 2 46 Spring 1
13 Bush 2 47 Release Lever 1
14 Washer 4
272466
48
Handle
(For Models Between
2010 and 2014)
1
15 Bush 2
16 Nut 2
272480
Handle
(For Models Between
2010 and 2014)
1
272639
17
Steering Wheel
(For Models Between
2010 and 2014)
2
49 Retaining Ring 1
272488
Steering Wheel
(For Models Between
2010 and 2014)
2
50 Washer 1
51 Ball Bearing 1
18 Wheel Yoke 1 52 Snap Ring 1
19 Screw 2 53 Spacer 1
20 Nut 2 54 Spacer 1
21 Screw 3 55 Fork 1
22 Spacer 1 56 Hooked Plate 1
23 Bush 1 57 Spacer 2
24 Pin 2 58 Spacer 2
25 Bush 2 59 Pin 2
26 Hold Yoke 1 60 Screw 2
27 Ball Bearing 1 61 Bush 2
28 Spacer 1 62 Handle Tube 1
