Electric Non-Telescoping High Lift Truck
(Part # 272460 & 272461)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR HIGH LIFT TRUCK,
READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
12. PART INFORMATION
(MODELS MANUFACTURED AFTER 2015)
12.6 PUMP PART LIST
Wesco
Replacement
Part #
No. Description Qty
Wesco
Replacement
Part #
No. Description Qty
301 Locking Ring 1
132068 320 Valve Cartridge 1
302 Gasket for Spring 1
321 Nut 1
303 Piston 1
322 Screw 1
304 Spring 1
323 Lever Plate 1
* 305 Dust Ring 1
324A Pump Body 1
* 306 Y-Ring 1
325 Cylinder 1
307 Pump Cylinder 1
* 326 Seal Gasket 1
* 308 O-Ring 1
327 Bushing 1
* 309 Seal Gasket 1
328 Screw Cover 1
310 Screw Plug 1
* 329 O-Ring 1
311 Screw Plug 1
* 330 Dust Ring 1
* 312 O-Ring 1
3323X Piston Rod 1
313 Adjusting Bolt 1
333A Piston 1
314 Spring 1
* 334A O-Ring 1
315 Spindle Safety Valve 1
* 335A O-Ring 1
316 Elastic Pin 1
* 336A Gasket 1
317 Lower Cylinder 1
337 Elastic Collar 1
* 318 O-Ring 1
* 338A Y-Ring 1
* 319 O-Ring 1
132078 Seal Kit 1
*ItemsincludedinSealKitP/N132078
