©Copyright 2018 WESCO Industrial Products, LLC. Specifications subject to change. Not responsible for errors or omissions.
Electric Non-Telescoping High Lift Truck
(Part # 272460 & 272461)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR HIGH LIFT TRUCK,
READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
10. PART INFORMATION
(MODELS MANUFACTURED BEFORE 2010)
10.3 FRAME PART DIAGRAM
10.4 FRAME PART LIST
Wesco
Replacement
Part #
No. Description Qty
Wesco
Replacement
Part #
No. Description Qty
201 Fork Frame 1 214 Elastomeric Gasket
202 Bolt 1 215 Nut 2
203 Screw 2 216 Inner Leg 1
204 Gasket 2 217
205 Screw 2 218 Elastic collar 4
206 Pin 2 219 Shaft of Roller 2
207 Bushing 2 220
208 Elastic collar 10 221
209 Left Leg 2 222 Roller 2
210 Bushing 2 223 Steel Roller 4
211 Pin 2 224 Gasket 4
212 Centrifugal Axle 2 225 Bearing 4
213 Bushing 2
