Folding Handle Scissors Lift Table
(Part # 260207 & 260208)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR SCISSORS LIFT TABLE,
READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
10. GENERAL ASSEMBLY PART INFORMATION
10.2 GENERAL ASSEMBLY PART LIST
Item Part Number Item Description Qty.
2 Handle Bar 1
3 Bolt M8 x 25 12
4 Washer 8 25
5 Washer 8 13
6 Nut M8 13
8 260238 Universal Wheel 5” 2
9 Frame 1
10 Shaft 2
11 260298 Wheel 5” 2
12 Retaining Ring for Axle 12 2
14 260280 Shaft 1
15 260281 Roller 1
16 260282 Retaining Ring for Axle 10 1
17 260283 Pin 1
18 260284 Bushing 1
19 260285 Retaining Ring for Axle 20 2
20 260286 Pump Arm 1
21 260287 Bumper 1
22 Bolt M8 x 30 1
23 Pedal Bar 1
24 Table 1
25 Retaining Ring for Axle 16 6
26 Washer 16 4
27 Washer 2
28 Washer 2
29 Roller 2
30 Bush 2
31 L-Pin 4
32 Bolt M6 x 10 4
33 Shaft 1
34 Arm 1
35 Bush 2
40 Pump 1
41 Support 2
42 Washer 2
43 Retaining Ring for Axle 24 2
44 Washer 6 4
46 260288 Bushing 1
47 Bush 4
48 Hollow Shaft 2
49 260299 Bearing 6203 4
