Folding Handle Scissors Lift Table
(Part # 260207 & 260208)
Instruction Manual
ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR SCISSORS LIFT TABLE,
READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.
9. PUMP PART INFORMATION
9.2 PUMP PART LIST
Item
Part
Number
Item Description Qty. Item
Part
Number
Item Description Qty.
260230
Complete Pump Replacement
(For 260207 Only)
1
20 Adjusting Screw 1
21 O-Ring 7.5 x 2.65 2
260232
Complete Pump Replacement
(For 260208 Only)
1
22 Cover Ring 1
23 Steel Ball 9.5 1
260231
Full Set of Seal Kits
(For 260207 Only)
1
24 Spring 1
25 Steel Ball ½ (12.7) 1
260233
Full Set of Seal Kits
(For 260208 Only)
1
26 Screw M16 x 18 1
27 Strike Pin 1
1 O-Ring 1
28 O-Ring 6.9 x 1.8 2
2
Pump Cylinder (260207) 1
29 Shaft 1
Pump Cylinder (260208) 1
30 Filter 1
3
YX-Seal Ring (260207) 1
31 O-Ring 65 x 3.55 1
YX-Seal Ring (260208) 1
32 Rectangular Ring Section 1
4
Dust Ring (260207) 1
33 Cylinder 1
Dust Ring (260208) 1
34 Housing 1
5
Pump Plunger (260207) 1
35 Screw 1
Pump Plunger (260208) 1
36 Retaining Ring for Axle 25 1
6 Spring 1
37 Washer 1
7 Spring Seat 1
38 O-Ring 33.5 x 3.55 1
8 Retaining Ring for Axle 10 1
39 Cup Packing 1
9 Joint Plate 2
40 Bush 1
10 Pin 1
41 O-Ring 20 x 2.65 1
11 Screw 1
42 Piston Rod 1
12 Copper Washer 20 1
43 Rectangular Section Sealing 1
13 Damp Valve 1
44 Cylinder Cap 1
14 Spring 1
45 O-Ring 31.5 x 3.55 1
15
Spring Seat 1
46
J Shaped Steel Frame
Rubber Sealing 32 x 45 x 6.5
1
16 Steel Ball 6.35 2
47 Base 1
17 Steel Ball 4.5 1
48 Lever Plate 1
18 Spring Seat 1
49 Retaining Ring for Axle 8 1
19 Spring 1
