6
WESAUDIO
4/25/16
TIMBRE USER MANUAL
2. Front Panel
1 2 3 4 5 6 7 8
1. Input – determines the level of the input signal entering the Timbre, as well as the threshold.
Higher settings will increase amounts of compression or limiting.
2. Mode- provides three distinct flavors of attack & recovery characteristic.
SINGLE –Provides a simple slow attack that is very smooth.
DOUBLE –Provides an intelligent program-controlled attack and release characteristic that brings up
density and detail without pumping like traditional compressors.
TRIPLE- Provides the program-controlled characteristic with extra fast attack, for maximum density.
It is only recommended with small amounts of gain reduction.
3. Recovery – gives six release times. The first (left) position is the standard slow release time. Each
click to the right is progressively faster.
4. S.C FILTER – enables high-pass side chain filter in the detector chain which makes compressor
less sensitive in low frequency band.
5. Comp IN – engage the compressor, when switch is in the off position signal is hard bypassed by
relay.
6. Link – enables link function when you want to connect two units together (more info in Linking
compressors section).
7. Output – determines the level of the output signal. Is is used to recover compression lost signal.
8. Power- main power switch.
