WESAUDIO
9/14/22
_PHOEBE USER MANUAL
8
4. Module installation and compatibility.
WesAudio _PHOEBE compressor module is designed to be installed into an API™ 500 Series
compatible rack or in ng500 rack (e.g., _TITAN) and cannot function stand alone, requiring the power
source supplied by the rack system.
Important NOTE:
Unit produces fair amount of heat because of its power consumption, it is highly
recommended to leave empty space above and below chassis to allow proper air
circulation. Ideally 1U space above, and 1U space below.
After unpacking your _PHOEBE module, please check for any visible damage that may have occurred
during transit. If there is any problem, please contact your dealer immediately for an advice on how to
proceed.
!!!Ensure the rack is completely powered down before attempting
installation to prevent damage to the module and yourself!!!
Module installation walkthrough:
Choose the position in the rack to which you will install the module and slide it in so that the edge
connector of the module aligns with the matching connector in the rack. A gentle push and the module
should slide home into the rack connector. Attach the front panel to the front of the rack with screws
supplied by your rack manufacturer. This is important for mechanical rigidity. Do not over tighten these
screws to avoid stripping out the threads. Apply power, test that everything is working OK, and most
importantly, enjoy!
500 series compatibility note:
Each WesAudio device in ng500 (Next Generation 500 series) product line is equipped with special
connector. This connector is an extension to 500 series and allows your device to be managed/recalled
through specialized GCon protocol (e.g., _Titan 500 series 10 slots frame).
Commented [RW3]: Tubes ?
