WESAUDIO
9/14/22
_PHOEBE USER MANUAL
6
1. Introduction
_PHOEBE is fully analog unit with digital control - whole audio processing is done ONLY through analog
components. Digital side is responsible to configure device accordingly, which allows to implement digital
recall and remote control of the unit.
2. Main Features
100% analog microphone/line preamp with +28dBu of headroom.
Class A fully analog - inspired by famous 1073 design based on dual amp topology.
Microphone gain up to 75dB.
Carnhill Transformers (input and output).
Output signal metering on the front panel with clip detection.
Phantom power and phase invert control.
Switchable input impedance (1200/300Ohm).
All controls/analog settings are fully manageable via the WesAudio GCon DAW
plug-in.
IRON PAD - passive output attenuation circuit with 1 dB step
(after the output transformer).
Front panel XLR/TRS socket which supports - HiZ instrument input (TS), line input
(XLR), microphone input (XLR).
Recallable signal source to be either back XLR Socket, or front panel
XLR/TRS socket.
500 series and ng500 (e.g. _TITAN) series compatible.
Total Recall and plugin control compatible with most DAWs.
Analog automation in DAW.
Fully digitally controlled and isolated analog circuit,
Digital recall can be achieved by connecting unit directly through front
panel mini-USB socket, or using it inside _TITAN chassis,
Accurate analogue Output signal metering and its precise simulation implemented in the plug-in itself,
Free software and firmware upgrades.
Commented [RW1]:
Commented [RW2]: TS ?
