WESAUDIO
4/8/25
NGTUBECOMP USER MANUAL V2
17
1. AC Power Socket: This is the designated point on the unit where the power cable is connected, linking
the device to the main electrical supply. It's through this connection that the device draws alternating
current (AC) power, essential for its operation. The socket is designed to accommodate the specific
type of power cord that corresponds with the electrical standards of the region, ensuring the unit is
powered safely and efficiently.
2. Voltage Selector: This feature provides the option to switch the unit's operating voltage between 115V
(60Hz) and 230V (50Hz), catering to different regional electrical standards. It's crucial to use the
correct fuses for the voltage setting you select to prevent damage. Always replace the fuses with the
appropriate ones before changing the voltage selector to match the mains electricity supply of
your location. This ensures the unit operates within its safety and performance specifications.
Failure to use the correct fuse may result in internal damage, blown components, or pose a safety
risk. The correct fuse values and types for each voltage configuration are listed in the “Voltage
Selector and Fuses” section of this manual. If you're unsure about the proper settings, consult a
qualified technician or contact WesAudio support before powering the unit.
Digital Management Connections: The ngTubeComp facilitates digital management through two
connection options:
3. USB: Features a USB2+ compatible port for GCon management.
4. Ethernet: Offers an Ethernet port for GCon management using the UDP protocol (LAN within a single
subnet).
Please be aware that only one type of connection can be active at any given time. To use the Ethernet
connection, ensure the USB cable is disconnected from the unit's rear.
5. SIGNAL CONNECTORS - each channel contains following signal connectors:
1. XLR IN – Input signal via XLR cable,
2. XLR OUT – Output signal via XLR cable,
6. Serial Number.
2.4 Audio Signal Connectivity
The ngTubeComp is a state-of-the-art device that marries the warmth and richness of analog signal
processing with the precision and flexibility of digital control. This means that while your audio signal paths are
purely analog, passing through the device via XLR connections on the back panel for pristine quality, the
extensive range of the unit's functions and parameters can be meticulously adjusted through a digital
management protocol. Each channel's input and output are facilitated through these XLR sockets, ensuring
high-quality, interference-free audio transmission.
