WESAUDIO
4/8/25
NGTUBECOMP USER MANUAL V2
12
11. Saturation: Adds tonal coloration and harmonic depth to the signal, enhancing warmth, richness, and
analog character depending on the selected saturation path.
• THD (Total Harmonic Distortion): The knob adjusts saturation levels from 0% to 100%. At
0% position (fully left), the THD circuit is bypassed.
• Tube: Reconfigures the gain staging between the vari-mu compression tube and the output
stage. The higher the parameter value, the stronger the signal hitting the compression tube —
while maintaining the same compression level thanks to dynamic circuit adaptation.
12. OUTPUT Control: Adjust OUTPUT level from – 15dB to +15dB in 0.25dB steps, with distinct
parameters for RED and GREEN modes. Pushing the knob switches between RED and GREEN modes.
For more information about OUTPUT parameter please refer to OUTPUT Modes chapter.
13. IRON PAD: Engages a passive attenuation circuit, active only in RED mode, for gain attenuation
between 0dB and 15dB.
14. Sidechain: Shapes how the compressor reacts to incoming audio by modifying the detection signal,
offering creative and technical control over compression behavior.
• HPF (High Pass Filter): Filters low-frequency content in the sidechain path to prevent over-
compression from bass-heavy signals like kicks or sub-bass.
• High-Bell Boost: Accentuates high frequencies in the sidechain path, increasing the
compressor’s sensitivity to transients and brightness.
• Listen Mode: Routes the sidechain signal to the output for monitoring, allowing precise tuning
of sidechain filters and their influence on compression behavior. This function is activated
when the IRON PAD button is pushed, enabling quick access for detailed sidechain analysis.
