M405 p/n 2M-305101 Owmers Manual Drop-In Refrigerated Cold Pans
5
INSTALLATION
NOTE: DO NOT discard
the carton or other packing
materials until you have
inspected the appliance for
hidden damage and tested it
for proper operation.
Refer to SHIPPING DAMAGE
CLAIM PROCEDURE on the
inside front cover of this
manual.
WARNING:
RISK OF PERSONAL
INJURY
Installation procedures must
be performed by a qualied
technician with full knowledge
of all applicable electrical and
plumbing codes. Failure can
result in personal injury and
property damage.
IMPORTANT:
Unit must remain in an upright
position during installation
to prevent damage to the
refrigeration system.
IMPORTANT:
Refrigeration system is air
cooled. Recommend louvered
grills or equivalent openings
front and rear, each with a
minimum size of twice the
surface area of the condenser,
to provide adequate air
circulation.
IMPORTANT:
Access is required for the
operation of the drain valve
and for maintenance of the
refrigeration unit. Provide
adequate access to the drain
valve and refrigeration unit.
IMPORTANT:
Unit ange must be sealed
to the counter top. Damage
caused by leaks due to
improper installation is NOT
covered by warranty.
UNPACKING & INSPECTION
Carefully remove the appliance from the carton. Remove all protective
plastic lm, packing materials and accessories from the Appliance
before connecting electrical power or otherwise performing any
installation procedure.
Carefully read all instructions in this manual and the Installation
Instruction Sheet packed with the appliance before starting any
installation.
Read and understand all labels and diagrams attached to the
appliance.
Carefully account for all components and accessories before discarding
packing materials. Store all accessories in a convenient place for later
use.
RCP units must remain upright at all times (shipping and installation)
to prevent damage to the condensing unit. If the unit is accidentally
tipped, allow unit to sit upright for at least 24 hours before connecting to
electric power.
COMPONENTS
1 ea. PAN RAIL
1 - 5 ea. PAN ADAPTER BAR ( quantity differs with unit)
PREPARATION
Cutout dimensions for tank units and control panels are listed on the
Installation Instructions provided with the unit.
Provide at least 1” clearance around the condensing unit chassis.
Countertop must be at and level before the unit is installed. After
cutout is made, add stiffeners or bottom braces to counter as required
to support unit weight.
IMPORTANT:
Refrigeration system is air cooled. Recommend louvered grills or
equivalent openings front and rear, each with a minimum size of
twice the surface area of the condenser, to provide adequate air
circulation.
NOTE: The condenser fan is provided with a fan guard.
DO NOT remove the condenser fan guard.
Provide louvered grills and service access below control panel. Provide
access to the POWER SWITCH and TEMPERATURE CONTROL UNIT
located at the front of the condenser.
Verify that provided sealants are applied to the underside of the top
ange prior to setting the unit into the cutout.
After installation, apply a thin bead of food-grade silicone sealant
around the ange to seal it to the counter.
Avoid storing ammable or combustible materials in, on or near the
appliance.
Clean the unit thoroughly after installation and before rst use.
