M011C.02 2M-Z16298 Owners Manual for Built-In Well Modular Warmers
PARTS LIST: M300-327 SERIES
18
Model: Modular Warmers M300-327T, TD, TDM, TDMAF, TN, M300-327E, CE, ED, EDM, EDMAF, EN
Fig No Part No Description Qty Application
1 P2-31869 SCREEN DRAIN ASSY WARMER 3 DRAIN UNITS
2
P2-Z14636 PAN ASSY 12X20 EAF W/TEE
1
M300 DIGITAL
P2-Z14647 PAN ASSY 12X27 EAF M327 DIGITAL
P2-WL0066 PAN ASSY MODTDMNAF W/ELBOW M300 T-STAT NARROW
WS-503893 PAN ASSY 200-500TDM A/F M300 T-STAT & INFINITE
WS-504101 PAN ASSY 12X27 AF M327 T-STAT
3
P2-Z14639 PAN ASSY 12X20 E
3
M300 DIGITAL
P2-Z14637 PAN ASSY 12X20 ED w/DRAIN M300 DIGITAL DRAIN
P2-Z14638 PAN ASSY 12X20 EDM M300 DIGITAL DRAIN, MANIFOLD
P2-Z14646 PAN ASSY 12X27 EDM
M327 DIGITAL, DRAIN, MANIFOLD
2 M327 DIGITAL, AUTOFILL
P2-WL0064 PAN ASSY W/ELBOW MODTDMN 2
M300 T-STAT, NARROW, AUTOFILL
M300 T-STAT & NARROW
P2-WL0065 PAN ASSY MID MOD300TDMN 1 M300 T-STAT, NARROW, 2-ELBOWS
WS-55741 PAN W/O DRAIN 200-500 / T
3
M300 T-STAT & INFINITE
WS-53201 PAN W/DRAIN 200-500 /TD M300 T-STAT & INFINITE, DRAIN
WS-55742 PAN W/DRAIN 200-500DM/TDM
M300 T-STAT & INFINITE, DRAIN, MANIFOLD
2 M300 T-STAT DRAIN, AUTOFILL
P2-WL0263
PAN ASSY MOD W/T DRN
PASSIVATED
3
MOD300TDMTHP
D8-301955 PAN ASSY SMPT-27 / MOD M327 T-STAT
P2-WL0061 PAN ASSY w/DRAIN M127TD M327 T-STAT, DRAIN
WS-500700 PAN ASSY 12X27 TDM M327 T-STAT, DRAIN, MANIFOLD
4 2V-35609 VALVE 1 IN GATE BRONZE 1 MANIFOLD UNITS
5 WS-503713 PROBE ASSY, SS AUTOFILL WRMR 1 AUTOFILL UNITS
6 2K-48198 ELBOW 3/8 X 90DEG BRASS 1 AUTOFILL UNITS
7 2K-48197 NIPPLE 3/8 NPT X 2 BRASS 1 AUTOFILL UNITS
8 2V-47650 VALVE ANTISYPHON 3/8 1 AUTOFILL UNITS
9 2K-47662 FTG STR BRS 3/8NPT X3/8IN 1 AUTOFILL UNITS
10 2C-46591 CLAMP HOSE 5/8 2 AUTOFILL UNITS
11 2K-31040 BUSHING 7/8 OD 1 THERMOSTAT UNITS
12 WS-50131 TERM BLOCK KIT (RETRO 30131) 1 INFINITE & AUTOFILL UNITS
13 2C-41974 NUT 8-32 HEX 7/8 LONG ALU 2 AUTOFILL UNITS
14
2J-30385 LIGHT SIGNAL GLO DOT RED
3
INFINITE UNITS
2J-35687 LIGHT SIGNAL GLO DOT T-STAT UNITS
15
P2-Z12592 PANEL, CONTROL
1
INFINITE UNITS NON-AF
P2-Z12586 PANEL, CONTROL MOD300TDM T-STAT UNITS
15 P2-Z12588 PANEL, CONTROL MOD600 TDM 1 M300/327 T-STAT, DRAIN, MANIFOLD
16 P2-46685 BOX OUTLET MOD300, 400, 500
1
T-STAT & INFINITE UNITS NON-AF
16 P2-48178 BOX OUTLET MOD600TDM AUTOFILL UNITS
17
2T-38968 THERMO K TYPE
3
T-STAT UNITS
2T-46551 THERMO CTRL 96IN CAP T-STAT UNITS w/ 96IN CAPILLARY
2T-45917 THERMO CTRL W/AUX WARMERS T-STAT UNITS, AUTOFILL
2E-30570 SWITCH INFINITE, 120V
3
INFINITE UNITS, 120V
2E-30562 SWITCH INFINITE, 240V INFINITE UNITS, 240V
18
2R-44373 KNOB CONTROL ASSY WARMERS
3
INFINITE UNITS
2R-40498 KNOB ASSY MOD 100DT T-STAT UNITS
19 P2-46587 HOSE MOD AUTOFILL 36” 1 AUTOFILL UNITS
