M011C.02 2M-Z16298 Owners Manual for Built-In Well Modular Warmers
PARTS LIST: DETAIL A
25
Detail A: Digital Control Box Assy
Fig No Part No Description Application
1 2A-Z3429 SPACER-NYLON .175X.375X.5 AUTO-FILL
2 2E-306865 CONTROL LIQ LEVEL 208/240 AUTO-FILL
3 2C-31053 NUT 8-32 KEPS MS NICKEL
4 2E-46529 SOLENOID VALV 1/4NPT 240 AUTO-FILL
5 2C-1493 SCREW 8-32X3/8 RHP STL NP AUTO-FILL
6
P2-Z14490 CONTROL BOX WELD - SMALL M200-227E
P2-Z14497 CONTROL BOX WELD - MEDIUM M200-227EAF, M300-327E
P2-Z14493 CONTROL BOX WELD - LARGE
M300-327EAF, M400/427E, M400/427EAF,
M500/527E, M500/527EAF
7 2C-35736 NUT 8-32 HEX KEPS MS GREE ALL
8 2E-37465 TERM BLOCK 3POLE 85AMP ALL
9 2C-1496 SCREW 8-32X3/4 RHP STL NP ALL
10 2C-Z2594 NUT 6-32 HEX W STL NP ALL
11
2E-Z14534 CONTROLLER, TEMP 230V AUTO-FILL
2E-Z14534-1 THERMISTOR, 90”
2E-Z14534-2 THERMISTOR, 126” 6’ LEAD
12 2K-Z1971 SPACER .257X.75X.25 NYLON AUTO-FILL
13 2C-200110 WASHER, #8 FLAT 18-8 SS ALL
14
2M-Z14495 GRAPHIC M200/227EAF M200-227E
2M-Z14498 GRAPHIC M200/227EAF M200-227EAF
2M-Z14499 GRAPHIC M300/327E M300-327E
2M-Z14526 GRAPHIC M300/327EAF M300-327EAF
2M-Z14527 GRAPHIC M400/427E M400/427E, M400/427EAF
2M-Z14529 GRAPHIC M500/527E M500/527E, M500/527EAF
15 2E-Z1858 SWITCH-LIGHTED AUTO-FILL
16 2C-33935 SCREW 6ABX5/16 PH PAN SMS ALL
17
P2-Z14494 CONTROL PANEL M200/227E M200-227E
P2-Z14496 CONTROL PANEL M200/227EAF M200-227EAF
P2-Z14522 CONTROL PANEL M300/327E M300-327E
P2-Z14524 CONTROL PANEL M300/327EAF M300-327EAF
P2-Z14525 CONTROL PANEL M400/427E M400/427E, M400/427EAF
P2-Z14492 CONTROL PANEL M500/527E M500/527E, M500/527EAF
18 2E-130601 WIRE ASSY 14GA GREEN 8” ALL
NI 2K-34136X FTG FLEX CON 90 X 1/2 MOD AUTO-FILL
