M011C.02 2M-Z16298 Owners Manual for Built-In Well Modular Warmers
PARTS LIST: M200-227 SERIES
Model: Modular Warmers M200-227T, TD, TDM, TDMAF, TN, M200-227E, CE, ED, EDM, EDMAF, EN
Fig No Part No Description Qty Application
1 P2-31869 SCREEN DRAIN ASSY WARMER 2 DRAIN UNITS
2
P2-Z14636 PAN ASSY 12X20 EAF W/TEE
1
M200 DIGITAL
P2-Z14647 PAN ASSY 12X27 EAF M227 DIGITAL
P2-WL0064 PAN ASSY W/ELBOW MODTDMN M200 T-STAT NARROW
WS-503893 PAN ASSY 200-500TDM A/F M200 T-STAT & INFINITE
WS-504101 PAN ASSY 12X27 AF M227 T-STAT
3
P2-Z14639 PAN ASSY 12X20 E
2
M200 DIGITAL
P2-Z14637 PAN ASSY 12X20 ED w/DRAIN M200 DIGITAL DRAIN
P2-Z14638 PAN ASSY 12X20 EDM M200 DIGITAL DRAIN, MANIFOLD
P2-Z14646 PAN ASSY 12X27 EDM
M227 DIGITAL, DRAIN, MANIFOLD
1 M227 DIGITAL, AUTOFILL
P2-WL0063 PAN ASSY AF MODTDMN
1
M200 T-STAT, AUTOFILL
WS-55742 PAN W/DRAIN 200-500DM/TDM
M200 T-STAT & INFINITE, DRAIN,
MANIFOLD
WS-55741 PAN W/O DRAIN 200-500 / T
2
M200 T-STAT & INFINITE
WS-53201 PAN W/DRAIN 200-500 /TD M200 T-STAT & INFINITE, DRAIN
WS-500700 PAN ASSY 12X27 TDM M227 T-STAT, DRAIN, MANIFOLD
4
2V-35609 VALVE 1 IN GATE BRONZE 1 MANIFOLD UNITS
5 WS-503713 PROBE ASSY, SS AUTOFILL WRMR 1 AUTOFILL UNITS
6 2K-48198 ELBOW 3/8 X 90DEG BRASS 1 AUTOFILL UNITS
7 2K-48197 NIPPLE 3/8 NPT X 2 BRASS 1 AUTOFILL UNITS
8 2V-47650 VALVE ANTISYPHON 3/8 1 AUTOFILL UNITS
9 2K-47662 FTG STR BRS 3/8NPT X3/8IN 1 AUTOFILL UNITS
10 2C-46591 CLAMP HOSE 5/8 2 AUTOFILL UNITS
11 2K-31040 BUSHING HEYCO 7/8 OD 1 THERMOSTAT UNITS
12 WS-50131 TERM BLOCK KIT (RETRO 30131) 1 INFINITE & AUTOFILL UNITS
13 2C-41974 NUT 8-32 HEX 7/8 LONG ALU 2 AUTOFILL UNITS
14
2J-30385 LIGHT SIGNAL GLO DOT RED
2
INFINITE UNITS
2J-35687 LIGHT SIGNAL GLO DOT T-STAT UNITS
15
P2-Z12288 PANEL, CONTROL
1
T-STAT & INFINITE UNITS NON-AF
P2-Z19780 CONTROL PANEL MOD227TDM-K
P2-Z12589 PANEL, CONTROL MOD 200/400 1 AUTOFILL UNITS
16
E7-49046 BOX OUTLET MOD WARM
1
T-STAT & INFINITE UNITS NON-AF
P2-Z19779 HOUSING CONTROL MOD227TDM-K
P2-48175 BOX OUTLET MOD200/400TDM AUTOFILL UNITS
17
2T-38968 THERMO K TYPE
2
T-STAT UNITS
2T-46551 THERMO CTRL 96IN CAP T-STAT UNITS w/ 96IN CAPILLARY
2T-45917 THERMO CTRL W/AUX WARMERS T-STAT UNITS, AUTOFILL
2E-30570 SWITCH INFINITE, 120V
2
INFINITE UNITS, 120V
2E-30562 SWITCH INFINITE, 240V INFINITE UNITS, 240V
18
2R-44373 KNOB CONTROL ASSY WARMERS
2
INFINITE UNITS
2R-40498 KNOB ASSY MOD 100DT T-STAT UNITS
20 2E-46529 SOLENOID VALVE 1/4NPT 240 1 AUTOFILL UNITS
21
P2-40843 BRKT MTG THERMO INFINITE
2
T-STAT & INFINITE UNITS
P2-48176 BRKT THERMO MOD200TDM AUT T-STAT AUTOFILL
22 2E-306865 CONTROL LIQ LEVEL 208/240 1 AUTOFILL UNITS
23 2I-40034 GROMMET SCREW T4 4 AUTOFILL UNITS
16
