2M-308017-011C Built-In Single Well Modular Warmer w/T-Stat Control
18
WIRING DIAGRAM
WATER FILL
VALVE
LOW WATER CONTROL
1
2
3
19
25
1
4
S1
HEATING ELEMENT
TEMP CONTROL
(BACK VIEW)
SENSOR
PROBE
INPUT
RELAY
L1 L2
L3
INPUT
NO
COMMON
MAX
NC
COM
34
35
36
37
38
WATER PAN
GRN
PROBE
101
102
L1=
1
101 3 102
COM
PROBE
1
2
3
4
19
37
34
35
36
38
2M-Z14564 rev~
SINGLE PHASE
POWER INPUT
ALTERNATE WATER
LEVEL CONTROL
NOTES: WIRING DIAGRAM MOD100E
1) GROUND TO EARTH USING SUPPLIED STUD
IN CONTROL BOX.
2) OPTIONAL WATER LEVEL CONTROL: WIRES
19 & 35 SHOULD BE CAPPED IF NOT USED.
L2=
VOLTS
WATTS
AMPS
120
1650
13.8
208
1240
6.0
220
1386
6.3
240
1650
6.9
MODEL
MOD100E
50/60HZ
21
22
1
2
3
HEATING ELEMENT
TEMP CONTROL
(BACK VIEW)
SENSOR
PROBE
INPUT
RELAY
2M-Z15015rev~
NOTES: WIRING DIAGRAM MOD100E
1) GROUND TO EARTH USING SUPPLIED STUD
IN CONTROL BOX.
VOLTS
WATTS
AMPS
120
1650
13.8
208
1240
6.0
220
1386
6.3
240
1650
6.9
MODEL
MOD100E
50/60HZ
101
102
USE WIRE NUTS FOR CORD ATTACHMENT
OR FIELD INSTALLED WIRING.
