2M-308017-011C Built-In Single Well Modular Warmer w/T-Stat Control
15
PARTS LIST: Detail A
Detail A: EMOD Control Box Assy
Fig No Part No Description Qty Application
1 P2-Z14490 CONTROL BOX WELD - SMALL 1
2 2C-31053 NUT 8-32 KEPS MS NICKEL 4
3 2C-35736 NUT 8-32 HEX KEPS MS GREE 1
4 2E-37465 TERM BLOCK 3POLE 85AMP 1
5 2C-1496 SCREW 8-32X3/4 RHP STL NP 2
6 2C-Z2594 NUT 6-32 HEX W STL NP 4
7
2E-Z14534 CONTROLLER, TEMP 208/240V
1
208/230/240V
2E-Z14528 CONTROLLER, TEMP 120V 120V
8 2K-Z1971 SPACER .257X.75X.25 NYLON 4
9 2C-200110 WASHER, #8 FLAT 18-8 SS 4
10 2E-130601 WIRE ASSY 14GA GREEN 8” 2
11
2E-Z1858 SWITCH-LIGHTED
1
120/208/240V
2E-Z3156 SW DPST 20A/125V ORG LGHT M100ED-230CE
12 2M-Z14491 GRAPHIC M100/127E 1
13 P2-Z14489 CONTROL PANEL M100/127E 1
13 P2-Z15013 CONT PANEL M100/127E 1
14 2C-33935 SCREW 6ABX5/16 PH PAN SMS 6
15 P2-Z15012 CONTROL BOX M100/127E 1
16 P2-Z15013 CONT PANEL M100/127E 1
17 2M-Z15026 GRAPHIC M100/127 E/ED 1
NI 2E-306865 CONTROL LIQ LEVEL 208/240 1 Auto-Fill
NI 2E-46529 SOLENOID VALVE 1/4NPT 240 1 Auto-Fill
NI 2E-200372 CORD SET, 12/3 CORD 6-20 1 208/240V
NI C3-G1204 CORD SET ASSEMBLY 1 120V
NI 2E-31200-01 BOX CONNECTOR 3/8 1 M100HCE
NI 2E-Z14534-1 THERMISTOR 90” RING TERM 1 STANDARD MODELS
NI 2E-Z14534-2 THERMISTOR 120” RING TERM 1 6’ CONDUIT MODELS
