2M-308017-011C Built-In Single Well Modular Warmer w/T-Stat Control
13
PARTS LIST
MOD-100T, MOD-100TD, MOD100HT, MOD100HTD, M100TDWA
Fig No Part No Qty Description Application
1
2N-300166UL
1
ELEM 208V 1650W MODS MOD100HTD208
2N-303375UL
ELEM HEATING 208/240V 1650W
(Dual Voltage)
MOD100T, MOD100TD, MOD100T6, MOD100TD6, MOD100HT
2N-46131UL ELEM 120V 1200W M100THTDM-120
2N-46660UL ELEM 240V 1200W LLW-1220 MOD100HTD
2N-46681UL ELEM 120V 1650W SMPT MOD100T-120V, MOD100T6-120V, MOD100TD-120, MOD100TD6120
2
P2-WL0071
1
PAN ELEM ASSY MOD100T 208
MOD100T, MOD100T-230, MOD100T6, MOD100TD, MOD100TD-230,
MOD100TD6 , MOD100TDAF
P2-WL0076 PAN ELEM ASSY MOD100HTD MOD100HTD208
P2-WL0077 PAN ELEM ASSY MOD100HT MOD100HT, MOD100HT6, MOD100HTW
P2-WL0772 ELMNT PAN ASSY 1.2K 120V M100HDTM-120
P2-WL0079 PAN ELEM ASSY MOD100HTD MOD100HTD
P2-WL0080 PAN ELEM ASSY MOD100T120V MOD100T-120, MOD100T6-120, MOD100TD-120, MOD100TD6120
3 D8-303352 1 BRKT THERMO BULB ALL
5 2H-36196 4.25 INSUL FG .6 MICRO 1X 45 ALL
6 2H-36050 1.75 INSUL FG .6 MICRO 1X36 ALL
7
P2-40628 2 SHROUD SIDE MOD100DT MOD100HTM MOD100HT6, MOD100HTD, MOD100HTD208
P2-45066 1 SHROUD WRAP MOD 100 ROHS MOD100T
8 P2-45067 1 SHROUD FR MOD 100 ROHS MOD100T
9
P2-40629
1
SHROUD BOT MOD100HT
MOD100HT, MOD100HT6, MOD100HTD, MOD100HT208,
MOD100HTW
P2-45186 SHROUD BOT MOD 100 ROHS
10 5P-21709 1 SCREEN DRAIN WARMERS ALL
11
P2-30401
1
PAN W/O DRAIN MOD100T
P2-30402 PAN W/ DRAIN MOD100TD, MOD100TD-120, MOD100TD6, MOD100TD6120
P2-44564 PAN ASSY SMP TMP MOD100H MOD100HT, MOD100HT6
P2-WL0056 PAN ASSY W/DRAIN MOD100HTD MOD100HTD, MOD100HTD208
P2-Z15007 PAN ASSY M100/127E M100E, M100CE, M100E6
P2-Z15011 PAN ASSY M100/127ED M100ED, M100ED6, M100CED, M100CED6
12 2K-33996X
2
FTG FLEX CONDUIT 90X3/8
ALL (EXCEPT MOES)
3 MOD100T-120V
13 2I-Z12311 2 GASKET-FIBER WASHER MOD100T
14 P2-Z16805 1 BOX, CONTROL ALL
15
2T-38968
1
THERMO K TYPE SS206ET R MOD100T, MOD100TD, MOD100HT, MOD100HTD, MOD100HTW
2T-46551 THERMO CTRL 96IN CAP RO MOD100T6, MOD100T6-120V, MOD100TD6120, MOD100HT6
16 P2-40843 1 BRKT MTG THERMO INFINITE MOD100T
17 2J-35687 1 LIGHT SIGNAL GLO DOT W#8 ALL
18 I7-Z12221 1 PANEL, FRONT MOD100T
19 2R-40498 1 KNOB ASSY MOD 100DT MOD100T, MOD100T-120V
20 2K-31040 1 BUSHING HEYCO 7/8 O.D. ALL
21 2C-30397 4 CLIP ELEM M P ALL
22
P2-45183
1
CONDUIT FLEX 3/8 X 28”
P2-Z18128 CONDUIT FLEX 3/8 X 10” MOD100TD-MOE, M100HTDM-120
23 WS-20176 1 ADAPT TOP 2 7QT STD 12X20 M100TDWA
