2M-Z21001 Rev- Owner's Manual for IRCS4 Impingement/Radiant Split-Belt Conveyor Toaster
17
2M-Z21876 Rev- Owner’s Manual for MDW Modular Dry Well
SPECIFICATIONS
AMPS
MODEL
TOP
WIDTH
[A]
BOTTOM
WIDTH
[B]
CONTROL
WIDTH
[C]
DEPTH
HEIGHT
BELOW
SURFACE
VOLTS,
PHASE
L1 L2 L3
TOTAL
kW
MDW100 14.8 in.
(376 mm)
13.2 in.
(335 mm)
5.9 in.
(149 mm)
20 in.
(508 mm)
11.9 in.
(302 mm)
208, 1Φ
240, 1Φ
2.9
3.3
0.61
0.8
MDW200 29.5 in.
(749 mm)
27.6 in.
(701 mm)
14.1 in.
(359 mm)
20 in.
(508 mm)
11.9 in.
(302 mm)
208, 1Φ
240, 1Φ
5.9
6.7
1.22
1.6
MDW300 43.5 in.
(1.1 m)
41.6 in.
(1.06 m)
18 in.
(457 mm)
20 in.
(508 mm)
11.9 in.
(302 mm)
208, 3Φ
240, 3Φ
5.1
5.8
5.1
5.8
5.1
5.8
1.83
2.4
MDW400 57.5 in.
(1.46 m)
55.6 in.
(1.41 m)
18 in.
(457 mm)
20 in.
(508 mm)
11.9 in.
(302 mm)
208, 3Φ
240, 3Φ
5.1
5.8
7.6
8.7
7.6
8.7
2.44
3.2
MDW500 71.5 in.
(1.82 m)
69.6 in.
(1.77 m)
18 in.
(457 mm)
20 in.
(508 mm)
11.9 in.
(302 mm)
208, 3Φ
240, 3Φ
7.6
8.7
7.6
8.7
10.1
11.5
3.05
4
MODEL
APPROX.
SHIP
WEIGHT
APPROX.
UNIT
WEIGHT
MDW100 34 lb.
(15.4 kg)
30 lb.
(13.6 kg)
MDW200 63 lb.
(28.6 kg)
55 lb.
(24.9 kg)
MDW300 160 lb.
(72.6 kg)
80 lb.
(36.3 kg)
MDW400 185 lb.
(83.9 kg)
105 lb.
(47.6 kg)
MDW500 210 lb.
(95.3 kg)
130 lb.
(59 kg)
MDW300 shown
20 in.
(508 mm)
A
B
C
9.8 in.
(249 mm)
12.3 in.
(312 mm)
23.6 in.
(599 mm)
12 in.
(305 mm)
Minimum of 4.1 inches (104 mm)
Minimum
of 3.1 inches
(79 mm)
2 in.
(51 mm)
1.25 in.
(32 mm)
1 in.
(25 mm)
21.7 in.
(302 mm)
2.9 in.
(74 mm)
The knock out is 0.875-inch
(22 mm) diameter on MDW100
models and is 1.125-inch (29 mm)
on all other models.
CLEARANCE
Do not install closer than six [6] inches (152 mm) to front
wall, one [1] inch (25 mm) to back and side walls, and
6.75 inches (171 mm) to a surface below the unit. If storage
is to be used underneath, it is recommended that a bae
be placed 8.5 inches (216 mm) below the unit to avoid
contact with elevated temperatures.
6.2 in.
(157 mm)
SAFETY SANITATION AGENCY LISTING INFORMATION
The nameplate of your unit will show the specific agency listing information.
