15
EXPLODED VIEW & PARTS LIST
M021A 2M-308085 Owners Manual for Built-In Bain Marie Warmers
HT300 & HT327 Built-in Baine Marine Style Heated Tanks
Fig No Part No Qty Description
1 P2-31869 1 SCREEN DRAIN ASSY WARMER
2 P2-301893 2 ADAPTER BAR HT200-500
3 DD-302884 2 ADAPTER BAR HT327/437 AF
4 P2-304105 2 SHROUD FRONT REAR HT-300
5 P2-303359 2 SHROUD SIDE MODS ROHS
6 P2-302882 2 SHROUD SIDE HT227/527 AF
7 2C-30397 AR CLIP ELEM M P
8 2N-46660UL 3 ELEM 240V 1200W LLW-1220
9 2N-300706UL 3 ELEM 240V 1650W 12 X 27
10
P2-WL0074 3 PAN ASSY W/ ELEMENT
WS-501759 3 PAN ASSY W/O ELEMENT
11 PS-302883 3 PAN ELEMENT HT227 / 527
12 D8-303352 3 BKT THERMO BULB
13 2V-47847 1 VALVE DRAIN BALL 1IN BRASS
14 2K-34136X 1 FTG FLEX CON 90X 1/2 MOD
15 P2-306959 1 BOX CONTROL MOD100T/WARMER
16 2T-45917 1 THERMO CTRL W/AUX WARMERS
17 P2-40843 1 BRKT MTG THERMO INFINITE
18 I7-Z12221 1 PANEL, FRONT
19 2J-35687 1 LIGHT SIGNAL GLO DOT
20 2R-40498 1 KNOB ASSY MOD 100DT
