17
EXPLODED VIEW & PARTS LIST
M021A 2M-308085 Owners Manual for Built-In Bain Marie Warmers
HT400 & HT427 Built-in Baine Marine Style Heated Tanks
Fig No Part No Qty Description
1 P2-31869 1 SCREEN DRAIN ASSY WARMER
2 P2-301893 3 ADAPTER BAR HT200-500
3 DD-302884 3 ADAPTER BAR HT327/437 AF
4 P2-304106 2 SHROUD FR/RR HT400/427
5 P2-303359 2 SHROUD SIDE MODS ROHS
6 P2-302882 2 SHROUD SIDE HT227/527 AF
7 2C-30397 AR CLIP ELEM M P
8 2N-46660UL 4 ELEM 240V 1200W LLW-1220
9 2N-300706UL 4 ELEM 240V 1650W 12 X 27
10
P2-WL0074 4 PAN ASSY W/ ELEMENT
WS-501759 4 PAN ASSY W/O ELEMENT
11 PS-302883 4 PAN ELEMENT HT227 / 527
12 D8-303352 4 BKT THERMO BULB
13 2V-47847 1 VALVE DRAIN BALL 1IN BRASS
14 2K-34136X 1 FTG FLEX CON 90X 1/2 MOD
15 WS-50131 1 TERM BLOCK KIT, 3-POLE 85AMP
16 E7-49046 1 BOX OUTLET MOD WARM FRY
17 2T-45917 2 THERMO CTRL W/AUX WARMERS
18 P2-40843 2 BRKT MTG THERMO INFINITE
19 P2-Z12288 1 PANEL CONTROL
20 2J-35687 2 LIGHT SIGNAL GLO DOT
21 2R-40498 2 KNOB ASSY MOD 100DT
