11
• Always maintain heat gun movement over the work surface
using a gentle back and forth movement while applying
heat unless you find that a concentrated application of heat
best delivers the desired results for a particular operation.
APPLICATIONS
Reduce the risk of heat damage and personal injury, shield
combustible materials and areas adjacent to the work piece.
Protect yourself from hot paint scrapings and dust.
SHRINKING TUBING
Shrink tubing is most often used in place of electrical tape
to hold joined wires in position and provide insulation. When
exposed to adequate heat, the tubing shrinks to the size and
shape of the wire it covers. Slide the tubing over the wire to
be insulated; hold the wire with one hand away from the hot
air stream and hold the heat gun in the other hand. Move the
tubing from side to side through the heated air ow until the
tubing has shrunk. If the wire must be held with both hands,
position the heat gun with the nozzle pointed upward by
resting the heat gun on the handle and the rear gun housing.
Then pass the tubing covered wire from side to side through
the hot air ow until the wire shrinks to the desired size. Re-
move the wire from the air ow and move the rocker switch
to the „OFF“ position.
STRIPPING PAINT
• Fit the wide „deflector“ accessory tip on to the heat gun
nozzle. This tip will spread the heat over a wider surface
area, speeding paint removal. The „deflector“ tip will also
help protect window glass from cracking due to thermal
shock when removing paint near the glass.
• Turn the heat gun on, starting in the „Low“ heat setting and
hold it about 1 inch from the painted surface being
stripped. The best combination of distance, heat range and
speed of stripping will be determined by experience.
• Work small areas, moving the gun slowly over the surface.
When the paint begins to blister and bubble, move the gun
steadily across the surface while scraping off the loosened
paint behind the heat gun. Use a scraper that best matches
the work surface shape and width of the paint loosened by
the heat gun‘s path. Preheating the scraper as you are
heating the painted surface will increase the speed of paint
stripping.
• Do not burn or heat the paint for too long since this will
make the paint more difficult to remove. For working in
confined areas, away from glass, remove the wide
deflector tip.
• When the job is completed, move the rocker switch to
„OFF“ and properly position the heat gun to cool, away
from combustible material.
MAINTENANCE / CLEANING
• Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and maybe damaged by their use.
Use clean cloths to remove dirt, dust, oil, grease, etc.
Do not at any time let brake uids, gasoline, petroleum
based products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or de-
stroy plastic which may result in serious personal injury.
Electric tools used on berglass material, wallboard,
spackling compounds, or plaster are subject to accelerated
wear and possible premature failure because the berglass
chips and grindings are highly abrasive to bearings, brushes,
commutators, etc. Consequently, we do not recommend
using this tool for extended work on these types of materials.
However if, you do work with any of these materials, it is
extremely important to clean the tool using compressed air.
LUBRICATION
This tool is permanently lubricated at the factory and requires
no additional lubrication.
SERVICE
• Have your power tool serviced by a qualified repair person
using only identical replacement parts. This will ensure that
the safety of the power tool is maintained.
• Service your power tool periodically. When cleaning a tool,
be careful not to disassemble any portion of the tool since
internal wires maybe misplaced or pinched.
WARRANTY
Weller supplies this device with a warranty valid for two (2)
years from the date of purchase. The warranty relates to
material and manufacturing defects and covers both replace-
ment parts and labour.
We shall only be liable for claims arising from a warranty
furnished by us if the quality or durability warranty has been
furnished by us in writing and using the term „Warranty“.
The warranty shall be void if damage is due to improper use
and if the device has been tampered with by unauthorized
persons.
WARNING
EN
ENGLISH
