Mechanical and electrical design
General
The door and the electronic timer with display and program-selection knob
are fitted at the front of the machine.
All control and indicating components, i.e. relays, level control, etc are
assembled under the top cover, easily accessible from the top of the machi-
ne for simplified servicing.
Main units
1 Electronic timer with display and program-selection knob for operating
the machine.
2 Door - with automatic locking device which remains locked throughout
the different wash processes.
3 Detergent supply box - three compartments for automatic injection of
powdered detergents and fabric softener.
4 Inner cylinder - of stainless steel supported at the rear by two ballraces.
5 Outer drum - of stainless steel (18/8) securely attached to the frame.
6 Wash and extraction motor - for reversing wash action and high speed
spin action.
7 Hot and cold water valves - program and level controlled solenoid valves
for filling with water, and for flushdown of automatic detergent dispenser.
8 Drain valve - the timer controlled valve for draining the machine of water.
9 Siphon breaker - to prevent water in the machine from re-entering the
water supply system.
10 Control unit - of plug in type.
F
15
